Effect of Previous Grain Size on Recystallization Texture and the Formability of the Nb Ferritic Stainless Steel

Abstract:

The ferritic stainless steels are materials used in several segments due to the excellent combination of mechanical properties and corrosion resistance. The mechanical properties of these alloys are strongly dependent on the microstructural characteristics and crystallography texture. The aim of this experimental study is to investigate the roles of the grain size of the hot rolled sample on the development of the microstructure, texture and formability of ferritic stainless steel. The main elements of chemical composition of the steel under investigation were 16.0 %Cr, 0.021 %C, 0.024 %N and 0.35 %Nb. Coarse and fine grains samples were cold rolled up to 90% thickness reduction and annealed at 880°C with soaking time of the 24 s. The texture measurements were performed by Electron Backscattered Diffraction (EBSD) in the longitudinal section. The formability was evaluated by the R-value and planar anisotropy (Δr) in tensile tests. The final microstructure after annealed was more homogenous for smaller initial grain size sample. This condition was favorable to develop γ-fiber, with sharpness intensity in 111121 components. The highest R-value and smallest planar anisotropy was obtained for a {111}/{001} ratio around 5.37. On the other hand, coarser initial grain size sample had showed a heterogeneous microstructure and texture, performing badly in mechanical tests (anisotropy).

• Periodical: Materials Science Forum (Volume 879)
• Pages: 1594-1599
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.1594
• Online since: November 2016
• Authors: Daniella Gomes Rodrigues*, Cláudio Moreira Alcântara, Dagoberto Brandão Santos, Tarcísio Reis de Oliveira, Berenice Mendonça Gonzalez
• Keywords: Formability, Grain Size, Recrystallization Texture

References

[1] F. Gao, Z. Liu, H. Liu, G. Wang, Texture evolution and formability under different hot rolling conditions in ultra purified 17%Cr ferritic stainless steels. Mater. Charact. 75 (2013) 93-100.

DOI: 10.1016/j.matchar.2012.09.006

[2] F. Gao, Z.Y. Liu, H.T. Liu, G.D. Wang, Evolution of Through-Thickness Texture in Ultra Purified 17% Cr Ferritic Stainless Steels, J. Iron Steel Res. Int. 20 (2013) 31–38.

DOI: 10.1016/s1006-706x(13)60079-5

[3] M.Y. Huh, O. Engler, Effect of intermediate annealing on texture, formability and ridging of 17%Cr ferritic stainless steel sheet. Mater. Sci. Eng. A. 308 (2001) 74–87.

DOI: 10.1016/s0921-5093(00)01995-x

[4] W. Du, L.Z. Jiang, Q.S. Sun, Z.Y. Liu, X. Zhang, Microstructure, Texture, and Formability of Nb+Ti Stabilized High Purity Ferritic Stainless Steel, J. Iron Steel Res. Int. 17 (2010) 47–52.

DOI: 10.1016/s1006-706x(10)60113-6

[5] W.B. Hutchinson, Development and control of annealing Development and control of annealing. Int. Met. Rev. 29 (1984) 25–42.

[6] D. Raabe, K. Lücke, Textures of ferritic stainless steels, Mater. Sci. Technol. 9 (1993) 302–312.

[7] R. Abbaschian, L. Abbaschian, R. E. Reed-Hill, Physical Metallurgy Principles. fourth ed, Cengage Learning, (2009).

[8] F.J. Humphreys, M. Hatherly, Recrystallization and related annealing phenomena, second ed., Elsevier, Amsterdam; Boston (2004).

[9] H. Inagaki, Fundamental Aspects of Texture Formation in Low Carbon Steel, ISIJ Int. 34 (1994) 313–321.

DOI: 10.2355/isijinternational.34.313

[10] G. Dieter, Mechanical Metallurgy. third ed., McGraw-Hill Education, London, (1988).

[11] K. M. Lee, M.Y. Huh, H.J. Lee, J.T. Park, J.S. Kim, E.J. Shin, O. Engler. Effect of hot band grain size on development of textures and magnetic properties in 2. 0% Si non-oriented electrical steel sheet, JMMM, 396, 2015. 53-64.

DOI: 10.1016/j.jmmm.2015.08.010

[12] Y. Yazawa, Y. Ozaki, Y. Kato, O. Furukimi, Development of ferritic stainless steel sheets with excellent deep drawability by {1 1 1} recrystallization texture control, JSAE Rev. 24 (2003) 483–488.

DOI: 10.1016/s0389-4304(03)00082-1

[13] R.K. Ray, J.J. Jonas, R.E. Hook, Cold rolling and annealing textures in low carbon and extra low carbon steels, International Materials Reviews. 39 ( 1994) 129-172.

DOI: 10.1179/imr.1994.39.4.129

[14] T. He, Y. Liu, W. Sun, L. Zuo, Formation of Nuclei With <110> and <112> Orientations IF Steel at Early Stage of Recrystallization Using EBSD Analysis, J. Iron Steel Res. Int. 20 (2013) 61–66.

DOI: 10.1016/s1006-706x(13)60157-0

[15] D.G. Rodrigues, T.R. Oliveira, D.B. Santos, B.M. Gonzalez, Influence of Annealing Heating Rate on Nb Ferritic Stainless Steel Microstructure and Texture, Mater. Sci. Forum. 753 (2013) 217–220.

DOI: 10.4028/www.scientific.net/msf.753.217

[16] J. Hamada, N. Ono, H. Inoue, Effect of Texture on r-value of Ferritic Stainless Steel Sheets, ISIJ Int. 51 (2011) 1740–1748.

DOI: 10.2355/isijinternational.51.1740
