Effects of Hydraulic Pressure on Shape Accuracy of Drawn Circular Cups during Micro Hydro Deep Drawing

Abstract:

Micro hydro deep drawing is a promising technology to fabricate micro metal products with complex 3D shapes. However, the size effects in the micro hydro deep drawing become considerable and significantly influence shape accuracy of drawn cups. In this study, a Voronoi micro scale simulation model was developed to consider the size effects of SUS304 foils. A surface layer model was additionally applied in the simulation to further explain the size effects. The micro hydro deep drawing experiments were conducted with annealed SUS304 foils and the drawn cups were examined. The wrinkling phenomenon was generally aggravated with the hydraulic pressure. Simulation results also show that the high hydraulic pressure does not improve the shape accuracy of the drawn cups as that in the normal scale hydro deep dawning process does. The simulation results are in accordance with the experimental results.

• Periodical: Materials Science Forum (Volume 879)
• Pages: 2274-2279
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.879.2274
• Online since: November 2016
• Authors: Liang Luo, Zheng Yi Jiang*, Dong Bin Wei, Hideki Sato, Tsuyoshi Furushima, Kenichi Manabe
• Keywords: Micro Hydro Deep Drawing, Micro Simulation, Size Effects, Wrinkling

References

[1] H. Wang, L. Gao, M. Chen, Hydrodynamic deep drawing process assisted by radial pressure with inward flowing liquid, Int. J. Mech. Sci., 53 (2011) 793-799.

DOI: 10.1016/j.ijmecsci.2011.07.002

[2] E. Taghipour, A. Assempour, The effects of proportional loading, plane stress, and constant thickness assumptions on hydro-mechanical deep drawing process, Int. J. Mech. Sci., 53 (2011) 329-337.

DOI: 10.1016/j.ijmecsci.2011.02.002

[3] A. Assempour, E. Taghipour, The effect of normal stress on hydro-mechanical deep drawing process, Int. J. Mech. Sci., 53 (2011) 407-416.

DOI: 10.1016/j.ijmecsci.2011.03.003

[4] H. Sato, K. Manabe, D. B. Wei, Z. Y. Jiang, D. Kondo, Micro Sheet Hydroforming Process of Ultra-Thin Pure Titanium Foil, Key Eng. Mater., 626 (2015) 397-401.

DOI: 10.4028/www.scientific.net/kem.626.397

[5] J. Kim, D. Yang, Prediction of wrinkling initiation in sheet metal forming processes, Eng. Computations, 20 (2003) 6-39.

DOI: 10.1108/02644400310458810

[6] M. Abbasi, M. Ketabchi, T. Labudde, U. Prahl, W. Bleck, New attempt to wrinkling behavior analysis of tailor welded blanks during the deep drawing process, Mater. Design, 40 (2012) 407-414.

DOI: 10.1016/j.matdes.2012.04.015
