Comparison of Microstructure and Mechanical Properties of Aluminum Components Manufactured by CMT

Abstract:

This paper presents an investigation on the microstructure and mechanical property of Al-alloy parts made by using additive manufacturing based on CMT (Cold Metal Transfer) welding technology. With the same 3D model and process parameters, a set of hollow cylindrical parts with 100 layers were built up using 2319, 4043, 5356 aluminum welding wires, respectively. Then their microstructure, tensile strength, and microhardness were tested and analyzed comparatively. The layer bands characteristics were obviously observed in both 2319 and 4043 parts. In the interlayer region of the 2319 parts, the segregation of alloying elements on the grain boundaries and inside the grains were significantly more than that in the fusion line region. For the microstructure of 4043 parts, the dendrites grow upward from the bottom without interruption in the fusion line region, and the continuous growth structure was maintained. There is no obviously change on the microhardness from the bottom to the top because the organization is uniform and there is no significant difference in the grain size. The ultimate strength and elongation in the horizontal direction were higher than those in the longitudinal direction, and the 5356 parts had best mechanical properties among the three materials. Ultrasonic method was also used to measure the Young's modulus of the additive manufactured parts. The Young's modulus measuring results were accordant with the results obtained by the mechanical property testing, and the error was within 3%.

• Periodical: Materials Science Forum (Volume 898)
• Pages: 1318-1324
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.898.1318
• Online since: June 2017
• Authors: Y. Zhao*, Jian Xiao, S.J. Chen
• Keywords: Additive Manufacturing, Aluminum Component, CMT, Mechanical Properties, Microstructure

References

[1] Donghong Ding, Zengxi Pan. Fabricating Superior NiAl Bronze Components through Wire Arc Additive Manufacturing. Materials, 2016, 9(8): 652.

DOI: 10.3390/ma9080652

[2] Chen Shen, Zengxi Pan. Fabrication of Fe-FeAl Functionally Graded Material Using the Wire-Arc Additive Manufacturing Process. Metallurgical and Materials Transactions B, 2016, 47: 763.

DOI: 10.1007/s11663-015-0509-5

[3] Panagiotis Kazanas, Preetam Deherkar. Fabrication of geometrical features using wire and arc additive manufacture. Journal of Engineering Manufacture, 2012, 226(6): 1042-1051.

DOI: 10.1177/0954405412437126

[4] Daniel Clark, Martin Bache, Mark T Whittaker. Shaped metal deposition of a nickel alloy for aero engine applications. Journal of Materials Processing Technology, 2008, 439–448.

DOI: 10.1016/j.jmatprotec.2007.10.051

[5] Martina, F., Colegrove, P.A., Williams, S.W. Microstructure of Interpass Rolled Wire + Arc Additive Manufacturing Ti-6Al-4V Components. Metall and Mat Trans A , 2015, 46: 6103.

DOI: 10.1007/s11661-015-3172-1

[6] Jikui Zhang, Xueyuan Wang. Sanjooram Paddea. Fatigue crack propagation behaviour in wire+arc additivemanufactured Ti-6Al-4V: Effects of microstructure and residual stress. Materials and Design, 2015, 90: 551-561.

DOI: 10.1016/j.matdes.2015.10.141

[7] Pedro Miguel Sequeira Almeida, S. Williams. Innovative process model of Ti-6Al-4V additive layer manufacturing using cold metal transfer. Conference Paper, (2010).

[8] Ouyang J H, Wang H, Kovacevic R. Rapid prototyping of 5356-aluminum alloy based on variable polarity gas tungsten arc welding: process control and microstructure. Materials and Manufacturing Processes, 2002, 17(1)-103-124.

DOI: 10.1081/amp-120002801

[9] Clark D , Bache M R , Whittaker M T. Shaped metal deposition of a nickel alloy for aero engine applications. Journal of Materials Processing Technology, 2008, 203(1-3): 439-448.

DOI: 10.1016/j.jmatprotec.2007.10.051

[10] Jikui Zhang, Xiang Zhang, Xueyuan Wang. Crack path selection at the interface of wrought and wire + arc additive manufactured Ti-6Al-4V. Materials and Design, 2016, 104: 365-375.

DOI: 10.1016/j.matdes.2016.05.027

[11] Paul A. Colegrove, Harry E. Coules, Julian Fairman. Microstructure and residual stress improvement in wire and arc additively manufactured parts through high-pressure rolling. Journal of Materials Processing Technology, 2013, 213: 1782-1791.

DOI: 10.1016/j.jmatprotec.2013.04.012

[12] Huijun Wang, Wenhui Jiang, Jiahu Ouyang, Radovan Kovacevic. Rapid prototyping of 4043 Al-alloy parts by VP- GTAW. Journal of Materials Processing Technology, 2004, 148, 93-102.

DOI: 10.1016/j.jmatprotec.2004.01.058

[13] J.J. Lin , Y.H. Lv, Y.X. Liu. Microstructural evolution and mechanical properties of Ti-6Al-4V wall deposited by pulsed plasma arc additive manufacturing. Materials and Design, 2016, 102: 30-40.

DOI: 10.1016/j.matdes.2016.04.018

[14] Tomas SKIBA, Bernd BAUFELD, Omer van der BIEST. Microstructure and Mechanical Properties of Stainless Steel Component Manufactured by Shaped Metal Deposition. ISIJ International, 2009, 49: 1558-1591.

DOI: 10.2355/isijinternational.49.1588
