Raman/Infrared Spectra and Microwave Dielectric Properties of 0.22CaTiO₃-0.78(Li_0.5Sm_0.5)TiO₃ Ceramics with MgO Additive

Abstract:

0.22CaTiO₃-0.78(Li_0.5Sm_0.5)TiO₃ + x wt% MgO (0.25 ≤ x ≤ 2.0) ceramics with pure perovskite structure were prepared by a conventional two-step solid-state reaction process. The effect of different content of MgO additive on the microwave dielectric properties of the 0.22CaTiO₃-0.78(Li_0.5Sm_0.5)TiO₃ ceramics was investigated in detail. The results of microwave dielectric properties showed that the permittivity (ε_r) and temperature coefficient of resonant frequency (τ_f) decreased gradually, while quality factor (Q×f) values increased when the x value increased. Raman spectra and infrared reflectivity spectra were used to study the relationship between vibrational modes and microwave dielectric properties. The harmonic oscillator model was used to fit infrared reflectivity spectra, and the obtained complex dielectric response was extrapolated down into the microwave region. It was found that the complex dielectric spectra were in good agreement with the measured microwave permittivity and dielectric loss. The 0.22CaTiO₃-0.78(Li_0.5Sm_0.5)TiO₃ + 0.50 wt% MgO ceramic sintered at 1240°C for 4 h exhibited good microwave dielectric properties with ε_r = 102.6, Q×f = 5084 GHz (at 3.8 GHz), and τ_f = -16.3 ppm/°C.

• Periodical: Materials Science Forum (Volume 913)
• Pages: 473-479
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.913.473
• Online since: February 2018
• Authors: Fan Fan Ning*, Juan Jiang, Tian Jin Zhang
• Keywords: Dielectric Property, Infrared Reflectivity, Microwave Ceramic, RAMAN

References

[1] R. Lowndes, F. Azough, R. Cernik, R. Freer, Structures and microwave dielectric properties of Ca(1−x)Nd2x/3TiO3 ceramics, J. Eur. Ceram. Soc. 32 (2012) 3791-3799.

DOI: 10.1016/j.jeurceramsoc.2012.05.024

[2] M. Mirsaneh, I.M. Reaney, Y. Han, I. Sterianou, O.P. Leisten, Low sintering temperature high permittivity glass ceramic composites for dielectric loaded microwave antennas, Adv. Appl. Ceram. 110 (2013) 387-393.

DOI: 10.1179/1743676111y.0000000031

[3] W. -B. Li, D. Zhou, H. -H. Xi, L. -X. Pang, X. Yao, N. Alford, Structure, Infrared Reflectivity and Microwave Dielectric Properties of (Na0. 5La0. 5)MoO4-(Na0. 5Bi0. 5)MoO4 Ceramics, J. Am. Ceram. Soc. 99 (2016) 2083-(2088).

DOI: 10.1111/jace.14175

[4] H. Kagata, J. Kato, Dielectric Properties of Ca-Based Complex Perovskite at Microwave Frequencies, Jpn. J. Appl. Phys. 33 (1994) 5463-5465.

DOI: 10.1143/jjap.33.5463

[5] H. Takahashi, Y. Baba, K. Ezaki, Y. Okamoto, K. Shibata, K. Kuroki, S. Nakano, Dielectric Characteristics of (A1+ 1/2A3+ 1/2)TiO3 Ceramics at Microwave Frequencies, Jpn. J. Appl. Phys. 30 (1991) 2339-2342.

DOI: 10.1143/jjap.30.2339

[6] E.S. Kim, K.H. Yoon, Microwave dielectric properties of (1−x)CaTiO3–xLi1/2Sm1/2TiO3 ceramics, J. Eur. Ceram. Soc. 23 (2003) 2397-2401.

DOI: 10.1016/s0955-2219(03)00192-4

[7] Y.M. Li, T.T. Song, F. Hu, R.H. Liao, B. Zhang, Microwave Dielectric Properties of Ca1-x(Li1/2Sm1/2)xTiO3 Ceramics, Adv. Mater. Res. 105-106 (2010) 238-241.

[8] F. -f. Gu, G. -h. Chen, C. -l. Yuan, C. -r. Zhou, T. Yang, Y. Yang, Low temperature sintering and microwave dielectric properties of 0. 2Ca0. 8Sr0. 2TiO3–0. 8Li0. 5Sm0. 5TiO3 ceramics with BaCu(B2O5) additive and TiO2 dopant, Mater. Res. Bull. 61 (2015).

DOI: 10.1016/j.materresbull.2014.10.025

[9] W. Chang, L. Sengupta, MgO-mixed Ba0. 6Sr0. 4TiO3 bulk ceramics and thin films for tunable microwave applications, J. Appl. Phys. 92 (2002) 3941-3946.

DOI: 10.1063/1.1505669

[10] J.S. Park, Y.H. Han, Effects of MgO coating on microstructure and dielectric properties of BaTiO3, J. Eur. Ceram. Soc. 27 (2007) 1077-1082.

[11] S.Y. Wu, Y. Li, X.M. Chen, Raman spectra of Ba6−3xSm8+2xTi18O54 solid solution, J. Phys. Chem. Solids. 64 (2003) 2365-2368.

DOI: 10.1016/s0022-3697(03)00273-7

[12] T. Hirata, K. Ishioka, M. Kitajima, Vibrational Spectroscopy and X-Ray Diffraction of Perovskite Compounds Sr1−xMxTiO3 (M = Ca, Mg; 0 ≤ x ≤ 1), J. Solid State Chem. 124 (1996) 353–359.

DOI: 10.1006/jssc.1996.0249

[13] U. Balachandran, N.G. Eror, Laser-induced Raman scattering in calcium titanate, Solid State Commun. 44 (1982) 815-818.

DOI: 10.1016/0038-1098(82)90280-0

[14] C.H. Perry, B.N. Khanna, G. Rupprecht, Infrared Studies of Perovskite Titanates, Phys. Rev. 135 (1964) A408-A412.

DOI: 10.1103/physrev.135.a408

[15] K.W. Sup, Y.K. Hyun, K.E. Soo, Microwave Dielectric Properties and Far‐Infrared Reflectivity Characteristics of the CaTiO3–Li(1/2)−3xSm(1/2)+xTiO3 Ceramics, J. Am. Ceram. Soc. 83 (2000) 2327-2329.

DOI: 10.1111/j.1151-2916.2000.tb01557.x

[16] W. -B. Li, D. Zhou, D. Guo, L. -X. Pang, G. -H. Chen, Z. -M. Qi, Q. -P. Wang, H. -C. Liu, Structure, Raman spectra, far-infrared spectra and microwave dielectric properties of temperature independent CeVO4-TiO2 composite ceramics, J. Alloy. Compd. 694 (2017).

DOI: 10.1016/j.jallcom.2016.09.327
