Density Variations during Solidification of Grey Cast Iron

Abstract:

As part of moving towards a sustainable production of diesel engines for heavy vehicle applications, the ability to predict casting defects has become ever so important. In order to model the solidification process for cast components correctly, it is of essence to know how the material will actually behave. To produce sound castings, often of complex geometry, the industry relies on various simulation software for the prediction and avoidance of defects. Thermophysical properties, such as density, play an important part in these simulations.Previous measurements of how the volume of liquid grey iron changes with temperature has been made with a conventional dilatometer. Measurements have also been made in the austenitic range, then on iron-carbon-silicon alloys with a carbon content lower than 1.5 wt%. Based on these measurements the density variations during solidification were calculated. The scope for this paper is to model the volume changes during solidification with the control volume finite difference method, using data from the density measurements.

• Periodical: Materials Science Forum (Volume 925)
• Pages: 155-162
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.925.155
• Online since: June 2018
• Authors: Kristina Hellström*, Péter Svidró, Lucian Vasile Diaconu, Attila Diószegi
• Keywords: Density, Grey Cast Iron, Measurement, Modelling, Simulation

References

[1] T. Kusakawa, S. Kim, T. Kondo, Volume change of molten spheroidal graphite cast iron. 1972, Report of the Castings Research Laboratory: Waseda University. pp.23-32.

[2] K. Hellström, A. Diószegi, L. Diaconu, A broad literature review of density measurements of liquid cast iron. Metals, 7(5) (2017).

DOI: 10.3390/met7050165

[3] J. Blumm, J.B. Henderson, Measurement of the volumetric expansion bulk density of metals in the solid and molten regions. High Temp. - High Pressures, 32(1) (2000) 109-113.

DOI: 10.1068/htwu520

[4] I. Jimbo, A.W. Cramb, The Density of Liquid Iron-Carbon Alloys. Metall. Trans. B. 24B (1993) 5-10.

[5] H. Mizukami, A. Yamanaka, T. Watanabe, Prediction of density of carbon steels. ISIJ Int. 42(4) (2002) 375-384.

DOI: 10.2355/isijinternational.42.375

[6] J. Hattel, Fundamentals of Nummerical Modelling of Casting Processes, first ed, Polyteknisk Forlag, Kgs. Lyngby, Denmark, (2005).

[7] A. Dioszegi et al., Modelling and simulation of heat conduction in 1-D polar spherical coordinates using control volume-based finite difference method. Int. J. Numer. Methods Heat Fluid Flow, 26(1) (2016) 2-17.

DOI: 10.1108/hff-10-2014-0318

[8] S. Luo, W. Wang, M. Zhu, Cellular automaton modeling of dendritic growth of Fe-C binary alloy with thermosolutal convection. Int. J. Heat Mass Transfer, 116 (2018) 940-950.

DOI: 10.1016/j.ijheatmasstransfer.2017.09.074

[9] R.W. Lewis, K. Ravindran, Finite element simulation of metal casting. International Journal for Numerical Methods in Engineering, 47(1-3) (2000) 29-59.

DOI: 10.1002/(sici)1097-0207(20000110/30)47:1/3<29::aid-nme760>3.0.co;2-x

[10] T. Keller, et al., Application of finite element, phase-field, and CALPHAD-based methods to additive manufacturing of Ni-based superalloys. Acta Mater. 139 (2017) 244-253.

DOI: 10.1016/j.actamat.2017.05.003

[11] T. Skrzypczak, E. Węgrzyn-Skrzypczak, L. Sowa, Numerical modeling of solidification process taking into account the effect of air gap. Appl. Math. Comput. 321 (2018) 768-779.

DOI: 10.1016/j.amc.2017.11.023

[12] X.-G. Lu, M. Selleby, B. Sundman, Theoretical modeling of molar volume and thermal expansion. Acta Mater. 53(8) (2005) 2259-2272.

DOI: 10.1016/j.actamat.2005.01.049

[13] K. Hellström, L. Diaconu, and A. Diószegi, Density and thermal expansion coefficient of liquid grey cast iron and austenite. Submitted to Metallurgical and Materials Transactions A. (2017).

DOI: 10.1007/s41230-020-0035-1

[14] P. Svidró, A. Diószegi. Extended Method of Volume Change Measurement at the Solidification of Lamellar Graphite Iron. in International Symposium on the Science and Processing of Cast Iron (SPCI-XI). 2017. Jönköping, Sweden: Trans Tech Publication Ltd.

DOI: 10.4028/www.scientific.net/msf.925.163
