Melt Stirring of Nodular Cast Iron

Abstract:

In this work the effects of stirring/vigorous shearing on matrix and graphite phase in nodular cast iron melt during solidification were studied. Several experiments were conducted for different cooling and stirring times. Samples were prepared and examinations of the microstructure were conducted and compared using Leica Optical Microscope and Scanning Electron Microscope (SEM). In addition, a chemical analysis of the graphite precipitate was performed using EDX equipment mounted on SEM. Oxidation of the melt and formation of oxide nuclei during stirring were observed and analysed. The influence of melt shearing on the structure, nodule count, distribution, area fraction and on overall graphite precipitation was observed and examined with the help of respective computer programs and soft wares. Stirring resulted in increasing the nucleation sites for graphite precipitation thereby increasing the nodule count and area fraction of carbide and transforming the structure from pearlitic matrix to ferritic matrix.

• Periodical: Materials Science Forum (Volume 925)
• Pages: 125-132
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.925.125
• Online since: June 2018
• Authors: Fareed Ashraf Khan*, Hasse Fredriksson
• Keywords: Ductile Cast Iron, Formation of Graphite Strings, Melt Shearing, Melt Stirring, Nodular Cast Iron, Nodule Count, Nodule Distribution, Nucleation in Cast Iron, Oxidation of Melt, Turbulent Flow of Melt

References

[1] I. T. Im, W. S. Kim, K.S. Lee, A unified analysis of filling and solidification in casting with natural convection, Int. J. Heat Mass Tran. 44 (2001) 1507-1515.

DOI: 10.1016/s0017-9310(00)00197-6

[2] N. P. Yadav, Deepti Verma, Prediction of Solidification Behavior of Al Alloy in a Cube Mold Cavity, International Journal of Materials and Metallurgical Engineering 9 (No:12) (2015) 1418-1426.

[3] Hasse Fredriksson, Ulla Åkerlind, Materials Processing During Casting,. ISBN: 978-0-470-01514-8.

[4] C. R. Swaminathan, V. R. Voller, A time-implicit filling algorithm, Appl. Math. Model. 18 (1994) 101-108.

[5] S.N. Lekakh, J. Qing, V.L. Richards, K.D. Peaslee, Graphite Nodule Size Distribution in Ductile Iron, AFS Proceedings 2013 – American Foundry Society, Schaumburg, IL. Panel 13-1321.

[6] ASM Specialty Handbook Cast Irons: Editor: J.R. Davis, 1996, ISBN: 978-0-87170-564-8.

[7] Spheroidal graphite cast irons – Classification, ISO 1083:(2004).

[8] Janina M. Radzikowska. Metallography and Microstructures, ASM Handbook Volume 9, 2004, pp.565-587.

[9] F. Neumann, Giesserei 83 (1996) 11-15.

[10] J. Müller, W. Siefer, Giessereiforschung 45 (1993) 92-98.

[11] Qin Ziqiang, Yu Zongsen, Mechanism of inoculation of cast iron, Acta Metall Sin, 1 (1988) 67-71.

[12] Hasse Fredriksson, Ulla Akerlind, Solidification and Crystallization Processing in Metals and Alloys, 2012, ISBN: 978-1-119-99305-6. Page 175-182.

[13] G.M. Goodrich, Cast Iron Microstructure Anomalies and Their Causes, AFS Trans. 105 (1997) 669-684.

[14] H. Muhammad, F. Khan, A. Jutner, H. Fredriksson, Structure investigation of downhill and uphill casted inserts. Accepted for publication in SKB journal, (2017).

[15] H.J.T. Ellingham, Transactions and Communication, J. Soc. Chem. Ind. 63 (5) (1944) 125-160.
