Numerical and Experimental Investigation of the Heat Treated Steel Part Microstructure and Hardness

Abstract:

The approach for coupled experimental and numerical estimation of the heat treated steel part microstructure and hardness is presented. The method is based on the investigation of the austenite transformation in a steel during continuous cooling, Jominy hardenability test and numerical modeling of a quenching process. The presented approach is verified by estimation of the 20CrMo5 steel gear shaft microstructure and hardness. The estimated results are in good agreement with the experimental ones.

• Periodical: Materials Science Forum (Volume 946)
• Pages: 346-350
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.946.346
• Online since: February 2019
• Authors: Mikhail V. Maisuradze*, Alexandra A. Kuklina
• Keywords: CCT Diagram, Hardness, Heat Treatment, Jominy Test, Microstructure, Modeling, Steel

References

[1] V.M. Farber, O.V. Selivanova, O.N. Polukhina, A.B. Arabey, A.S. Mamatnazarov, Effect of heat treatment on mechanical properties of steels of strength class K65 (X80), Met. Sci. Heat Treat. 56 (2014) 454–456.

DOI: 10.1007/s11041-014-9781-2

[2] M.A. Ryzhkov, M.V. Maisuradze, Y.V. Yudin, A.V. Khuppeev, K.P.A. Babu, Experience in improving silicon steel component heat treatment quality, Metallurgist. 59 (2015) 401–405.

DOI: 10.1007/s11015-015-0117-2

[3] Y.A. Samoilovich, Increasing the Service Life of Large Rolling-Mill Rolls by Using the Reserve Hardenability of the Steel, Metallurgist. 59 (2015) 604–612.

DOI: 10.1007/s11015-015-0146-x

[4] B. Barroqueiro, J. Dias-De-Oliveira, J. Pinho-Da-Cruz, A. Andrade-Campos, Multiscale analysis of heat treatments in steels: theory and practice, Fin. Elem. Anal. Design. 114 (2016) 39–56.

DOI: 10.1016/j.finel.2016.02.004

[5] X. Jie, J. Hui, Numerical modeling of coupling thermal–metallurgical transformation phenomena of structural steel in the welding process, Adv. Eng. Soft. 115 (2018) 66–74.

DOI: 10.1016/j.advengsoft.2017.08.011

[6] B.L. Ferguson, Z. Li, A.M. Freborg, Modeling heat treatment of steel parts, Comp. Mater. Sci. 34 (2005) 274–281.

DOI: 10.1016/j.commatsci.2005.02.005

[7] I. Magnabosco, P. Ferro, A. Tiziani, F.Bonollo, Induction heat treatment of a ISO C45 steel bar: Experimental and numerical analysis, Comp. Mater. Sci. 35 (2006) 98–106.

DOI: 10.1016/j.commatsci.2005.03.010

[8] P. Cao, G. Liu, K. Wu, Study of heat treatment parameters for large-scale hydraulic steel gate track, Water Sci. Eng. 6 (2013) 423–432.

[9] N.S. Bailey, C. Katinas, Y.C. Shin, Laser direct deposition of AISI H13 tool steel powder with numerical modeling of solid phase transformation, hardness, and residual stresses, J. Mater. Proces. Tech. 247 (2017) 223–233.

DOI: 10.1016/j.jmatprotec.2017.04.020

[10] D. Chaouch, S. Guessasma, A. Sadok, Finite Element simulation coupled to optimisation stochastic process to assess the effect of heat treatment on the mechanical properties of 42CrMo4 steel, Mater. Design. 34 (2012) 679–684.

DOI: 10.1016/j.matdes.2011.05.026

[11] K. Gao, X. Qin, Z. Wang, H. Chen, S. Zhu, Y. Liu, Y. Song, Numerical and experimental analysis of 3D spot induction hardening of AISI 1045 steel, J. Mater. Proces. Tech. 214 (2014) 2425–2433.

DOI: 10.1016/j.jmatprotec.2014.05.010

[12] M.V. Maisuradze, M.A. Ryzhkov, Y.V. Yudin, A.A. Kuklina, Transformations of Supercooled Austenite in a Promising High-Strength Steel Grade Under Continuous Cooling Conditions, Met. Sci. Heat Treat. 59 (2017) 486–490.

DOI: 10.1007/s11041-017-0176-z

[13] R.N. Penha, J. Vatavuk, A.A. Couto, S.A.D.L. Pereira, S.A. de Sousa, L.D.C.F. Canale, Effect of chemical banding on the local hardenability in AISI 4340 steel bar, Eng. Fail. Anal. 53 (2015) 59–68.

DOI: 10.1016/j.engfailanal.2015.03.024

[14] L. Morales-Rivas, H. Roelofs, S. Hasler, C. Garcia-Mateo, F.G. Caballero, Detailed characterization of complex banding in air-cooled bainitic steels, J. Min. Metal. B. 51 (2015) 25–32.

DOI: 10.2298/jmmb140331008m

[15] Y.V. Yudin, M.V. Maisuradze, M.A. Ryzhkov, P.D. Lebedev, S.A. Musikhin, Simplified simulation method of round steel bar cooling, ISIJ Int. 55 (2015) 1538–1540.

DOI: 10.2355/isijinternational.55.1538

[16] M.V. Maisuradze, M.A. Ryzhkov, Yu.V. Yudin, Rapid Evaluation of the Cooling Capacity of Quenching Media, Met. Sci. Heat Treat. 57 (2015) 515–518.

DOI: 10.1007/s11041-015-9914-2

[17] ASM Handbook. Vol. 1. Properties and Selection. Irons, Steels, and High-Performance Alloys. ASM International, (1990).

DOI: 10.31399/asm.hb.v01.9781627081610

[18] C.R.N. Nunura, C.A. dos Santos, J.A. Spim, Numerical–Experimental correlation of microstructures, cooling rates and mechanical properties of AISI 1045 steel during the Jominy end-quench test, Mater. Design. 76 (2015) 230–243.

DOI: 10.1016/j.matdes.2015.03.031

[19] M. Pietrzyk, R. Kuziak, Computer aided interpretation of results of the Jominy test, Arch. Civil Mech. Eng. 11 (2011) 707–722.

DOI: 10.1016/s1644-9665(12)60111-3

[20] A.Z. Yazdi, S.A. Sajjadi, S.M. Zebarjad, S.M.M. Nezhad, Prediction of hardness at different points of Jominy specimen using quench factor analysis method, J. Mater. Proces. Tech. 199 (2008) 124–129.

DOI: 10.1016/j.jmatprotec.2007.08.035
