Thermo-Mechanical Reliability of 1200V-450A IGBT Module Considering Voids in the Solder Layer

Abstract:

1200V-450A IGBT power modules are fabricated in this paper. We study both the steady state and transient thermal performance of the IGBT assemblies by the finite element method using commercial software ANSYS Workbench to better understand the characteristic. Furthermore, power cycling tests indicate that inelastic strain increase as the numbers of cycles increase. In addition, X-ray photographs and ultrasound scan images were compared before and after the experiment. The thrust force of bonding wires decrease with increasing numbers of cycles, as indicated by tested.

• Periodical: Materials Science Forum (Volume 954)
• Pages: 202-209
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.954.202
• Online since: May 2019
• Authors: Xin Hua Guo*, Guang Deng Yang, Jin Yuan Fu, Ke Huang
• Keywords: ANSYS Workbench, Insulated Gate Bipolar Transistor (IGBT), Reliability, Thermo-Mechanical

References

[1] Jahdi S, Alatise O, Gonzalez J, et al. Temperature and Switching Rate Dependence of Crosstalk in Si-IGBT and SiC Power Modules[J]. IEEE Transactions on Industrial Electronics, 2016, 63(2):849-863.

DOI: 10.1109/tie.2015.2491880

[2] Mirzaee H , De A , Tripathi A , et al. Design comparison of high power medium-voltage converters based on 6.5kV Si-IGBT/Si-PiN diode, 6.5kV Si-IGBT/SiC-JBS diode, and 10kV SiC MOSFET/SiC-JBS diode[C]// IEEE Energy Conversion Congress & Exposition. IEEE, (2011).

DOI: 10.1109/ecce.2011.6064090

[3] Gao Y , Huang A Q , Krishnaswami S , et al. Comparison of static and switching characteristics of 1200 V 4H-SiCBJT and 1200 V Si-IGBT[J]. IEEE Transactions on Industry Applications, 2008, 44(3):887-893.

DOI: 10.1109/tia.2008.921408

[4] Sakka M A, Gualous H, Mierlo J V, et al. Thermal modeling and heat management of supercapacitor modules for vehicle applications[J]. Journal of Power Sources, 2009, 194(2):581-587.

DOI: 10.1016/j.jpowsour.2009.06.038

[5] Lefranc G, Mitic G, Licht T. Properties of solders and their fatigue in power modules[J]. Microelectronics Reliability, 2002, 42(9):1641-1646.

DOI: 10.1016/s0026-2714(02)00203-2

[6] Thebaud J M, Woirgard E, Zardini C, et al. Extensive fatigue investigation of solder joints in IGBT high power modules[C]// Electronic Components & Technology Conference, 2000. 2000 Proceedings. IEEE, 2000:1436-1442.

DOI: 10.1109/ectc.2000.853399

[7] Mei Y H, Lian J Y, Chen X, et al. Thermo-Mechanical Reliability of Double-Sided IGBT Assembly Bonded by Sintered Nanosilver[J]. IEEE Transactions on Device & Materials Reliability, 2014, 14(1):194-202.

DOI: 10.1109/tdmr.2013.2280668

[8] Chen G, Han D, Mei Y H, et al. Transient Thermal Performance of IGBT Power Modules Attached by Low-Temperature Sintered Nanosilver[J]. IEEE Transactions on Device & Materials Reliability, 2012, 12(1):124-132.

DOI: 10.1109/tdmr.2011.2173573
