The Eddy Current Method of Alloy Drill Pipes Wall Thickness Evaluation: Impact Analysis

Abstract:

The dependences of the surface eddy current probe added voltage at the interaction of the probe magnetic field with an aluminum pipe from the following main interference factors are determined: the pipe wall thickness, the gap between the probe and the surface of the pipe, the electrical conductivity of the material, the curvature of the pipe wall, the presence of areas with a smooth thickness change of the wedge character and a local spherical thinning, axis misalignment with respect to the pipe surface, the lateral misalignment of the probe axis. The problem is solved with the help of the finite element method (FEM). These data are consistent with the experimental results.

• Periodical: Materials Science Forum (Volume 970)
• Pages: 336-342
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.970.336
• Online since: September 2019
• Authors: Aleksandr E. Goldshtein, Vasily Y. Belyankov*
• Keywords: Alloy Drill Pipe, Eddy Current, Multifrequency, Wall Thickness

References

[1] Y. K. Fedosenko, V. G. Gerasimov, A. D. Pokrovskiy, Y. Y. Ostanin, Nondestructive Testing, Book 2: Eddy current testing, in: V. V. Klyuev (Ed.), Spectr publishing house, Moscow, (2010).

[2] A. E. Shubochkin, The development and present state of the eddy current method of nondestructive testing, Spectr publishing house, Moscow, (2014).

[3] J. García-Martín, J. Gómez-Gil, E. Vázquez-Sánchez, Non-destructive techniques based on eddy current testing, Sensors 11 (2011) 256.

DOI: 10.3390/s110302525

[4] A. V. Egorov, Inspection of aluminum alloys by a multi-frequency eddy current method, Defence Technology 11 (2015) 103.

DOI: 10.1016/j.dt.2014.12.002

[5] V. Sandovskii, Measurements of the thickness and electrical conductivity of nonmagnetic plates by an eddy-current method, Measurement Techniques 55 (2013) 1201.

DOI: 10.1007/s11018-012-0108-7

[6] Anderson E R 2009 Aluminum alloy drill pipe in geothermal drilling. Technical and economical opportunities (Iceland: The school for renewable energy science) 126.

[7] M. Gelfgat, V. Basovich, A. Adelman, Aluminum may be key to long, deepwater wells, Offshore 67/9 (2007) 131.

[8] M. Xuefei, L. Yinzhao, Analytical solutions to eddy current field excited by a probe coil near a conductive pipe, NDT&E International 54 (2013) 69.

DOI: 10.1016/j.ndteint.2012.11.010

[9] L. Rosado, T. Santos, P. Ramos, P. Vilaça, M. Piedade, A differential planar eddy currents probe: Fundamentals, modeling and experimental evaluation, NDT&E International 51 (2008) 85.

DOI: 10.1016/j.ndteint.2012.06.010

[10] Y. Yating, D. Pingan, X. Lichuan, Coil impedance calculation of an eddy current sensor by the finite element method, Russian Journal of Nondestructive Testing 44 (2008) 296.

DOI: 10.1134/s1061830908040104
