Formation and Optical Properties of Thin Mg₂Ge Films on Si(001) Substrate

Abstract:

Thin Mg₂Ge films were grown using two methods: a co-deposition of Ge and Mg on Si substrate kept at room temperature followed by annealing at 200 °C (solid phase epitaxy – SPE) and reactive deposition epitaxy (RDE) of Ge and Mg on Si at 200 °C. Optical properties of these structures were investigated in the photon energy range of 0.02–6.2 eV. Based on optical functions calculation, it was shown that SPE growth results in formation of a crystalline layer of Mg₂Si, which exhibits a strong optical phonon originated from the substrate-film interface. In the case of RDE growth, the amount of Mg₂Si is sufficiently lower, but Mg‑Si-Ge compound phonon appears. The estimate of a fundamental indirect transition value in the film is 0.72 eV for SPE growth method and 0.56 eV for RDE due to the ternary compound Mg-Ge-Si at the film-substrate interface.

• Periodical: Solid State Phenomena (Volume 247)
• Pages: 66-72
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.247.66
• Online since: March 2016
• Authors: Dmitry L. Goroshko*, Evgeniy A. Chusovitin, Konstantin Nickolaevich Galkin, Igor M. Chernev, Nikolay G. Galkin
• Keywords: Band Gap, Germanide, Germanium, Magnesium, Optical Properties, Phonon Structure, Thin Films

References

[1] Y. Noda, H. Kon, Y. Furukawa, N. Otsuka, I.A. Nishida, K. Masumoto. Preparation and Thermoelectric Properties of Mg2Si1-xGex (x=0. 0∼0. 4), Solid Solution Semiconductors Mater. Trans. JIM, 33 (1992) 845-856.

DOI: 10.2320/matertrans1989.33.845

[2] J. Tani, H. Kido. Thermoelectric properties of Bi-doped Mg2Si semiconductors, Original Physica B 364 (2005) 218-223.

DOI: 10.1016/j.physb.2005.04.017

[3] V.K. Zaitsev, M.I. Fedorov, E.A. Gurieva, I.S. Eremin, P.P. Konstantinov, A. Yu. Samunin and M.V. Vedernikov, Highly effective Mg2Si1−xSnx thermoelectrics, Phys. Rev. B 74 (2006) 045207(1-8).

DOI: 10.1109/ict.2005.1519920

[4] Y. Hayakawa, M. Arianandhan, Y. Saito, T. Koyama, a. o., Growth of homogeneous polycrystalline Si1-xGex and Mg2Si1-xGex for thermoelectric application, Thin Solid Films 519 (2011) 8532-8537.

DOI: 10.1016/j.tsf.2011.05.033

[5] H. Ihoe-Mouko, C. Mercier, J. Tobola, G. Pont, H. Scherrer, Thermoelectric properties and electronic structure of p-type Mg2Si and Mg2Si0. 6Ge0. 4 compounds doped with Ga, J. Alloys & Comp. 509 (2011) 6503-6508.

DOI: 10.1016/j.jallcom.2011.03.081

[6] G. Joshi, H. Lee, Y.C. Lan, X.W. Wang, a. o., Enhanced Thermoelectric Figure-of-Merit in Nanostructured p-type Silicon Germanium Bulk Alloys, Nano Lett., 8 (2008) 4670-4673.

DOI: 10.1021/nl8026795

[7] X.W. Wang, H. Lee, Y.C. Lan, G.H. Zhu, a. o., Enhanced thermoelectric figure of merit in nanostructured n-type silicon germanium bulk alloy, Appl. Phys. Lett., 93 (2008) 193121(1-4).

[8] A.I. Boukai, Y. Bunimovich, J. Tahir-Kheli, J.K. Yu, W.A. Goddard, J.R. Heath, Silicon nanowires as efficient thermoelectric materials, Nature, 451 (2008) 168-171.

DOI: 10.1038/nature06458

[9] N.N. Gorobey, V.E. Korsukov, A.S. Lukyanenko, Peculiarities of the Ge(111)-(2×8) crystal face structure studied by electron energy loss spectroscopy, Technical Physics Letters, 29 (2003) 280-282.

DOI: 10.1134/1.1573290

[10] J. Tejeda, M. Cardona, N.J. Shevchik, D.W. Langer, E. Schönherr, Photoelectric Properties of Mg2Si, Mg2Ge, and Mg2Sn I. X-Ray Excitation, Phys. Stat. Sol. (b), 58 (1973) 189–200.

DOI: 10.1002/pssb.2220580118

[11] N.G. Galkin, A.M. Maslov and A.V. Konchenko, Optical and photospectral properties of CrSi2 A-type epitaxial films on Si(111), Thin Solid Films, 515 (1997) 207-216.

DOI: 10.1016/s0040-6090(97)00678-0

[12] W.C. Dash, R. Newman, Intrinsic Optical Absorption in Single-Crystal Germanium and Silicon at 77 K and 300 K, Phys. Rev. 99 (1955) 1151-1155.

DOI: 10.1103/physrev.99.1151

[13] R.A. Smith, Semiconductors, Cambridge University Press, Cambridge, (1978).

[14] R.D. Redin, R.G. Morris, and G.C. Danielson, Semiconducting properties of Mg2Ge single crystal, Physical review, 109 (1958) 1916-(1922).

[15] M.Y. Au-Yang and M.L. Cohen, Electronic structure and optical properties of Mg2Si, Mg2Ge and Mg2Sn, Physical Review, 178 (1969) 1358-1365.

[16] C.J. Buchenauer and M. Cardona, Raman Scattering in Mg2Si, Mg2Ge, and Mg2Sn, Physical Review B, 3 (1971) 2504-2509.

[17] K.N. Galkin, Mahesh Kumar, Govind, S.M. Shivaprasad, V.V. Korobtsov, N.G. Galkin. A study of the temperature dependence of adsorption and silicidation kinetics at the Mg/Si(111) interface, Thin Solid Films, 515 (2007) 8192-8196.

DOI: 10.1016/j.tsf.2007.02.041
