An Intelligent Grinding Wheel Wear Monitoring System Based on Acoustic Emission

Abstract:

Acoustic emission (AE) signals can provide tool condition that is critical to effective process control. However, how to process the data and extract useful information are challenging tasks. This paper presented an intelligent grinding wheel wear monitoring system which was embedded in a surface grinding machine. An AE sensor was used to collect the grinding signals. The grinding wheel wear condition features were extracted by a proposed novel method based on statistics analysis of the average wavelet decomposition coefficient. The detailed signal characteristics during different wear condition are described. A BP neural network was used to classify the conditions of the grinding wheel wear. The inputs of the neural network were the three extracted features, and the outputs were three different states of grinding wheel condition, namely primary wear, intermediate wear and serious wear. The intelligent monitoring system was evaluated through grinding experiments. The results indicate that the effectiveness of the proposed method for extracting features of AE signals and developed intelligent grinding wheel wear monitoring system are satisfied.

• Periodical: Solid State Phenomena (Volume 261)
• Pages: 195-200
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.261.195
• Online since: August 2017
• Authors: Ning Ding*, Chang Long Zhao, Xi Chun Luo, Jian Shi
• Keywords: Acoustic Emission (AE), Grinding Wheel Wear, Neural Network, Wavelet Decomposition

References

[1] Xiaoli Li, A brief review: acoustic emission method for tool wear monitoring during turning, International Journal of Machine Tools & Manufacture , 42 (2002) 157–165.

DOI: 10.1016/s0890-6955(01)00108-0

[2] Amin A Mokbel, T M A Maksoud. Monitoring of the condition of diamond grinding wheels using acoustic emission technique . Journal of Materials Processing Technology, 2000, 101: 292~297.

DOI: 10.1016/s0924-0136(00)00433-7

[3] S. Kamarthi, S. Kumara, P. Cohen, Wavelet representation of acoustic emission in turning process, Intell. Eng. Syst. Artif. Neural Netw. 5 (1995) 861–866.

[4] X. Li, Real-time detection of the breakage of small diameter drills with wavelet transform, Int. J. Adv. Manuf. Technol. 14 (8) (1998) 539–543.

DOI: 10.1007/bf01301696

[5] X. Li, Y. Yao, Z. Yaun, On-line tool condition monitoring system with wavelet fuzzy neural network, J. Intell. Manuf. 8 (4) (1997) 271–276.

[6] X. Chen, J. Tang, D. Dornfeld, Monitoring and analysis of ultraprecision metal cutting with acoustic emission, in: Proceedings of the ASME Dynamic Systems and Control ASME, New York, NY, USA, 1996, p.387–393.

[7] J. Shi, The surface roughness online identification research based on acoustic emission technology, Master thesis, Changchun University of Science and Technology, (Changchun, China, 2014), pp.32-35.
