Ultrafine Particle Removal in the Wafer Cleaning Process Using an Aqueous Solution with a High Concentration of Dissolved O₃ and HF

Abstract:

Sulfuric Peroxide Mixture (SPM, H₂SO₄ + H₂O₂) has been widely used in semiconductor manufacturing processes due to its high reactivity and attractive price. However, SPM releases SO₄^2- ions that can be high impact on the environmental contaminations. Therefore, the SPM process requires a high cost wastewater treatment. So, the development of alternative chemicals has been becoming an important task in the semiconductor manufacturing process. In this paper, we evaluated the feasibility of replacing SPM with dissolved ozone water (DIO₃) in the wafer cleaning process, and confirmed that the Particle removal efficiency (PRE) was improved around 68% by mixing with diluted hydrofluoric acid (DHF). And, the PRE was also increased when the concentration of ozone in dissolved ozone water increased. Additionally the PRE was improved up to 98% by combining physical cleaning after O₃ process.

• Periodical: Solid State Phenomena (Volume 314)
• Pages: 214-217
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.314.214
• Online since: February 2021
• Authors: Hyeon Joon Han*, Hunhee Lee, Charles Kim, Yongmok Kim, Jinok Moon, Dukmin Ahn, Seokjun Hong, Taesung Kim
• Keywords: Deionized Ozone-Water (DIO₃), Particle Removal, Photoresist (PR), Strip, Sulfuric Acid Peroxide Mixture (SPM)

References

[1] Kern, W: Handbook of semiconductor wafer cleaning technology (Noyes Publication, New jersey, 1993): pp.111-196.

[2] S.Y. Mun, K.C. Yoon and B.W. An: JJAP 41(12) (2002), p.7529.

[3] Haynes, W. M.: CRC handbook of chemistry and physics, CRC press (2014).

[4] Zhijie Lü et al.: J. Ceramic Processing Research. 18 (2017), P. 416.

[5] S. Verhaverbeke et al.: J. Electrochem.I Soc. 141 (1994), P. 2852.

[6] H. Namba et al.: Solid State Phenomena 103 (2005), p.83.

[7] Kern, W: Handbook of semiconductor wafer cleaning technology (William Andrew, 2007): p.224.
