The Investigation of Electret Film Durability in Polyethylene Terephthalate (PET) from a Certain Angle of their Application as Pressure Sensors

Abstract:

Article presents research methods and their results for 100μm polyethylene terephthalate PET film, from a certain angle of its application as pressure sensors. Film was polarized at 150V/μm electric field intensity in dwo different temperatures: 60°C and 90°C. Direction of polarization was measured by thermally stimulated depolarization current TSDC. Results shows presence of homo-and heterocharge. Relaxation was calculated by two methods: from relationship ln J (T) = const – W/kT and from relationship (T) = P (T) / J (T). Activation energy for heterocharge calculated by first relationship is 6.14 eV to 6.77 eV and its relaxation time in 24°C is ~1020 years. For second one relationship, relaxation time in 24°C is ~1035 years. Piezoelectric voltage in 33 direction is 74V for termination resistance 1014Ω and 30V for termination resistance 109Ωfor applied stress 10N/cm2 from 10 cm2 surface. Obtained results for studied PET film, encourage to use it in practice as pressure sensors.

You might also be interested in these eBooks

Mechanical and Aerospace Engineering, ICMAE2011

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 110-116)

Pages:

1252-1258

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.110-116.1252

Citation:

Cite this paper

Online since:

October 2011

Authors:

Ewa Klimiec, Wiesław Zaraska, Szymon Kuczyński, Monika Machnik

Keywords:

Activation Energy, PET, Pressure Sensor, TSDC

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Tsuey T. Wang, Production of Piezoelectric PVDF Films, US 4241128, (1980).

Google Scholar

[2] Suh K-S., Tanaka J., Damon D., What is TSC?, IEEE Trans. Electr. Insul., Vol. 8, No. 6, pp.13-20, (1992).

DOI: 10.1109/57.168887

Google Scholar

[3] Gross B., Electret Research–Stages in Its Development, IEEE Trans. Electr. Insul., Vol. EI-21 No. 3, 249-269, (1986).

DOI: 10.1109/tei.1986.349058

Google Scholar

[4] Bucci C, Fieschi R, Guidi G (1966) Phys Rev 148: 816.

Google Scholar

[5] Neagu E. R., Neagu R., The determination o relaxation parameters and their distributions using thermally stimulated discharge current measurements, J. Phys. D: Appl. Phys. 35, 2298-2303, (2002).

DOI: 10.1088/0022-3727/35/18/311

Google Scholar
