Study on Microstructure and Ferroelectricity of Strontium Barium Titanate Thin Films Prepared by Sol-Gel Processing

Abstract:

Sr_0.5Ba_0.5-xBi_xTiO₃ (SBT) thin films were fabricated on a Pt/SiO₂/Si substrate by sol-gel method. The effects of chelating agent acetylacetone (HAcHAc) on the formation temperature and the microstructure of Sr_0.5Ba_0.5-xBi_xTiO₃ (SBT) thin films were investigated in this paper. The microstructure of BST thin films was examined by XRD and TEM. It is found that Bi³⁺ doping decreases dielectric loss, improves frequency dispersion for BST thin films. The peak of temperature-dependence of dielectric constant of Bi³⁺-doped BST thin films is compressed and moves to a low-temperature region. An inclined angle of approximately 1.8o between the two different polarization vectors was observed for BST thin film from the results of high-resolution transmission electron microscopy (HRTEM). The Pr, Ps and Ec was 0.22μC/cm², 0.72μC/cm² and 60Kv/cm respectively for Sr_0.5Ba_0.485Bi_0.015TiO₃ thin film at 100Hz, 20V.

• Periodical: Applied Mechanics and Materials (Volume 320)
• Pages: 202-207
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.320.202
• Online since: May 2013
• Authors: Lian Wei Shan, Lai Guo Wang, Wei Li, Li Min Dong, Zhi Dong Han, Ze Wu, Xing Hua Fu, Wen Ping Hou
• Keywords: Bi-Doping, Ferroelectricity, SBT, Thin Film

References

[1] L. Jaemo, O. Auciello and P. K. Baumann, et al., Composition-control of magnetron- sputter-deposited (BaxSr1–x)Ti1+yO3+z thin films for voltage tunable devices, Appl. Phys. Lett. Vol. 76 (2000) No. 5, pp.625-627.

DOI: 10.1063/1.125839

[2] S.Y. Kuo, Dependence of luminescence efficiency on dopant concentration and sintering temperature in the erbium-doped Ba0.7Sr0.3TiO3 thin films, J. Appl. Phys. Vol.92 (2002) No. 2, pp.1868-1872.

DOI: 10.1063/1.1492870

[3] M. C. Gust, L. A. Momoda and N. D. Evans, et al., Crystallization of Sol–Gel-derived barium strontium titanate thin films, J. Am. Ceram. Soc. Vol. 84 (2001), pp.1087-1092.

DOI: 10.1111/j.1151-2916.2001.tb00794.x

[4] B. K. Park, J. H. Lee and D. Y. Kim, Positive temperature coefficient of resistance effect in heavily niobium-doped barium titanate by the growth of the double-twinned seeds, J. Am. Ceram. Soc., Vol. 84 (2001), pp.2707-2709.

DOI: 10.1111/j.1151-2916.2001.tb01077.x

[5] V. N. Tsygankov and V. V. Safonov, Dielectric properties of samarium substituted barium strontium titanate, J. Mater. Sci. Lett. Vol. 38 (2003) No. 4, pp.1269-1273.

[6] S. J. Lee, K. Y. Kang and S. K. Han, Phase formation and ferroelectricity of sol-gel derived (Pb, La)TiO3 thin films, Appl. Phys. Lett. Vol. 72 (1998) No. 3, pp.299-301.

DOI: 10.1063/1.120717

[7] R. Varatharajan, R. Jayavel and C. Subramanian, et al., Growth and characterization of Ce and Nb barium strontium titanate single crystals, Mater. Res. Bull. Vol. 35 (2000), pp.603-611.

DOI: 10.1016/s0025-5408(00)00252-x

[8] V. Craciun and R. K. Singh, Characteristics of the surface layer of barium strontium titanate thin films deposited by laser ablation, Appl. Phys. Lett. Vol. 76 (2000), pp.1932-1934.

DOI: 10.1063/1.126216

[9] S. Y. Cha, B. T. Jang and H. C. Lee, Effects of Ir electrodes on the dielectric constants of Ba0.5Sr0.5TiO3 films, Jpn. J. Appl. Phys. Vol. 38 (1999), pp.49-51.

[10] S. J. Lee, S. E. Moon, H. C. Ryu, et al., Low-frequency dielectric responses of barium strontium titanate thin films with conducting perovskite LaNiO3 electrode, Jpn. J. Appl. Phys. Vol. 41 (2002), pp.4597-4600.

DOI: 10.1143/jjap.41.4597

[11] Y. Gim, T. Hudson, and Y. Fan et al., Microstructure and dielectric properties of Ba1-xSrxTiO3 films grown on LaAlO3 substrates, Appl. Phys. Lett. Vol. 77 (2000), pp.1200-1202.

DOI: 10.1063/1.1289272

[12] P. K. Sharma, V. V. Varadan, and V. K. Varadan, Porous behavior and dielectric properties of barium strontium titanate synthesized by Sol-Gel method in the presence of triethanolamine, Chem. Mater. Vol. 12 (2000) No. 9, pp.2590-2596.

DOI: 10.1021/cm000041u

[13] J. G. Cheng, X. J. Meng and J. Tang, Pyroelectric Ba0.8Sr0.2TiO3 thin films derived from a 0.05 M solution precursor by sol-gel processing. Applied Physics Letters, Vol. 75 (1999) No. 21, pp.3402-3404.

DOI: 10.1063/1.125307
