The Concept of Robotic Station for Measurement of the Friction Force between Fibre-Optic Cable and Duct

Abstract:

The interaction of an optotelecommunication cable and casing depends on numerous factors e.g. the type of cable, its structure, dimensions, as well as applied lubricants and sliding layers [8]. In addition, the course of the cable, velocity of installation and its maximum force also play a role in the interaction of the tribological pair. The paper outlines the idea and operation of a robotized testing station for evaluation of sliding friction. The station enables cables’ friction to be determined in relation to the length of contact between the cable and the casing.

• Periodical: Applied Mechanics and Materials (Volume 844)
• Pages: 44-49
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.844.44
• Online since: July 2016
• Authors: Tomasz Klepka*, Paweł Zaprawa, Daniel Ghiculescu
• Keywords: Cable Duct Interaction, Polymer Pair Cooperation, Robotic Station, Tribology

References

[1] Ab-Rahman M. S., The Component Study Fiber-to-the Home Passive Optical Network (FTTH-PON) – Current and Future Implementation, Advances in Natural and Applied Sciences, 5, 2 (2011) 147-157.

[2] Bellcore: GR-356, Generic Requirements for Optical Cable Innerduct, Associated Conduit, and Accessories, USA (2008).

[3] Endo H., Marui E., Fundamental studies on friction and wear of engineering plastics, Industrial Lubrication and Tribology 56, 5 (2004) 283-287.

DOI: 10.1108/00368790410550697

[4] Griffioen W., Plumettaz G., Nobach H.G., Theory, Software, Testing and Practice of Cable in Duct Installation, International Wire & Cable Symposium (2006) 357-365.

[5] Griffioen W., The Installation of Conventional Fiber-Optic Cables in Conduits Using Viscous Flow of Air, Journal of Lightwave Technology, 7, 2 (1989) 297-302.

DOI: 10.1109/50.17770

[6] Heron R.W., Pfeiffer T., van Veen T., Smith J., Patel S.S., Technology Innovations and Architecture Solutions for the Next-Generation Optical Access Network, Bell Labs Technical Journal, 13 (2008) 163-182.

DOI: 10.1002/bltj.20289

[7] Hogari K., Yamada Y., Toge K., Design and performance of ultra-high-density optical fiber ribbons. Optical Fiber Technology, 16 (2010) 257-263.

DOI: 10.1016/j.yofte.2010.05.007

[8] Klepka T., Jeziórska R., Szadkowska A., Thin wall products made of modified high density polyethylene, Przemysł Chemiczny, 94, 8 (2015) 1352-1355: doi: 10. 15199/62. 2015. 8. 21.

DOI: 10.15199/62.2015.8.21

[9] Matthijsse P., Griffioen W., Matching optical fiber lifetime and bend-loss limits for optimized local loop fiber storage, Optical Fiber Technology, 11 (2005) 92-99.

DOI: 10.1016/j.yofte.2004.09.004

[10] Pearson E. R., The principles of fiber-optic cable installation, Cabling Installation & Maintenance (2012) 5-11.

[11] Polish Patent, 220 747, Method for measuring tribological effects, especially cable coating and inner surface of the channel (2012).

[12] US Patent, 6 390 139, Conduit pipe for telecommunication cable (2001).

[13] US Patent, 7 046 898, Conduit insert for optical fibre cable (2006).
