Absolutely Testing of Off-Axis Aspherical Mirror Using Dichotomy Computer-Generated Holograms

Abstract:

A method for absolutely testing off-axis aspherical mirror is presented. A dichotomy CGH including two zones on one substrate is designed. One sub aperture generates the spherical wave front that is used for calibrating the pattern errors of the hologram; the other sub aperture reconstructs the aspherical wave front to test the off-axis aspherical mirror. By means of known absolute interferometric methods, the aberrations of the calibration wave front can be obtained. These aberrations can be transferred to the null testing wave front. The testing method is explained and the dichotomy CGH is designed. Finally, a simulation result supports this absolutely testing method.

• Periodical: Advanced Materials Research (Volume 497)
• Pages: 142-145
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.497.142
• Online since: April 2012
• Authors: Chao Xie, Sheng Yi Li, Shan Yong Chen
• Keywords: Absolutely Testing, Dichotomy CGH, Off-Axis Aspherical Mirror

References

[1] M. Wang , D. Asselin et al: SPIE Vol. 6342(2006), p. 63421Y.

[2] R. Angel, J. Burge, J. L. Codona, W. Davison and B. Martin: SPIE Vol. 4840(2003), p.183.

[3] J. Burge, in: Quality and Reliability of Optical Systems, edtied by James Bilbro and Robert parks, Proc. SPIE (1993).

[4] S. Reichelt and H. Tiziani: Opt. Comm Vol. 220(2003), p.23.

[5] P. Mallik, in: Interferometry XIII: Techniques and Analysis, edtied by K. Creath and J. Schmit, Proc. SPIE(2006).
