Multi-Bubble Electrospinning of Nanofibers

Abstract:

Multi-bubble electrospinning is considered as one of efficient techniques which have potential for large scale production of nanofibers. However, there is a lack of published research to better understand the formation of bubbles and the mutual interference among these bubbles. In this paper, the formation methods of multiple bubbles on the free liquid surface were examined to determine which ones performed relatively well. The influence of solution concentration, applied voltage, gas pressure, liquid length and the shape of electrode on the process and morphology of nanofibers were also investigated. The results showed that multiple gas tubes in the solution was the best choice to produce stable multiple bubbles though the number of bubbles was less than that obtained by the other methods. Some important processing parameters, such as solution concentration, applied voltage and the shape of electrode, had an important influence on the morphologies of nanofibers. Finally, both experimental and theoretical investigations in this process proved that the mutual interference among bubbles existed during multi-bubble electrospinning process.

• Periodical: Advanced Materials Research (Volume 843)
• Pages: 26-33
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.843.26
• Online since: November 2013
• Authors: Xue Feng Sun, Yong Liu, Jian Liu, Rui Wang, Yan Li Hu
• Keywords: Bubble Electrospinning, Morpholoy, Multiple Bubbles, Nanofiber

References

[1] J.H. He, Y. Liu, L.F. Mo, Y.Q. Wan, and L. Xu, Electrospun Nanofibres and Their Applications, Smithers Rapra Technology.Shropshire, UK, 2008.

[2] Y. Cai, J.Y. Lin, B. Ding, J.Y. Yu, Morphology Study of the Hybrid Electrospun Polystyrene- Nanoparticle Fibers, Journal of Modern Textile Science and Engineering. 1 (2010) 11-18.

[3] X. Fang, S.L. Xiao, M.W. Shen, R. Guo, S.Y. Wang, X.Y. Shi, Super Dye Removal Capability of Zero-Valent Iron Nanoparticle -Immobilized Electrospun Polymer Nanofibrous Membranes, Journal of Modern Textile Science and Engineering. 1 (2010) 1-10.

[4] P. Heikkilä, N. Olin, J.P. Nikkanen, Preparation of Electrospun TiO2 Using Nanosized TiO2 and Liquid Titanate Compound, Journal of Modern Textile Science and Engineering, 2 (2011) 1-12.

[5] Y. Liu, J.H. He, Bubble Electrospinning for Mass Production of Nanofibers, Int J Nonlinear Sci Numl. 8 (2007) 393-396.

[6] Y. Liu, Z.F. Ren, S. Wang, Theoretical Analysis and Experimental Verification of the Effect of Surface Tension on Morphology of Nanofibers in Bubble Electrospinning, Int. J. Nonlinear Sci. Num. Simul. 11 (2010) 625-630.

DOI: 10.1515/ijnsns.2010.11.8.625

[7] Y. Liu, L. Dong, J. Fan, R. Wang, J.Y. Yu, Effect of Applied Voltage on Diameter and Morphology of Ultrafine Fibers in Bubble Electrospinning, J. Appl. Polym. Sci. 120 (2011) 592-598.

DOI: 10.1002/app.33203

[8] J.S. Varabhas, S. Tripatanasuwan, G.G. Chase, D.H. Reneker, Electrospun jets launched from polymeric bubbles, Journal of Engineered Fibers and Fabrics. 4 (2009) 46-50.

DOI: 10.1177/155892500900400413

[9] J.H. He, Y. Liu, L. Xu, Apparatus for preparing electrospun nanofibres: a comparative review, Mater. Sci. Technol. 26 (2010) 1275-1287.

DOI: 10.1179/026708310x12798718274430

[10] Y. Liu, Z.F. Ren, J.H. He, Bubble electrospinning method for preparation of aligned nanofibre mat, Mater. Sci. Technol. 26 (2010) 1309-1312.

DOI: 10.1179/026708310x12798718274359

[11] Z.F. Ren, J.H. He, Single Polymeric Bubble for the Preparation of Multiple Micro/Nano Fibers, J. Appl. Polym. Sci. 119 (2011) 1161-1165.

DOI: 10.1002/app.32780

[12] J.H. He, Effect of Temperature on Surface Tension of a Bubble and Hierarchical Ruptured Bubbles for Nanofiber Fabrication, Thermal Science. 16 (2012) 327-330.

DOI: 10.2298/tsci111111033h

[13] Y. Liu, J.H. He, J.Y. Yu, H.M. Zeng, Controlling Numbers and Sizes of Beads in Electrospun nanofibers, Polym. 57 (2008) 632-636.

DOI: 10.1002/pi.2387

[14] W. Shou, L. Dong, Y. Liu, R.Wang, Mutual Interaction of the Electric Field in Multi-bubble Electrospinning, Nonlinear Sci. Lett. D. 2(2011) 119-121.
