Redistribution of Implanted Species in Polycrystalline Silicon Films on Silicon Substrate

Abstract:

Redistributions of implanted species after thermal annealing in polycrystalline silicon (poly-silicon) were studied by secondary ion mass spectrometry. Ten different elements were implanted into poly-silicon films grown on Si substrates. The implanted energies were chosen such that the expected ion range is within the poly-silicon film. Thermal anneals were carried out at temperatures between 300°C and 1000°C in flowing high purity Ar gas. Three different diffusion behaviors have been observed for these elements. For Be, Na, Ga, and Cr, most of the implanted ions diffused out to the surface of the poly-silicon film after anneal at 1000°C. For K, Ca, Ti, and Ge, the impurity ions diffused deeper into the bulk after anneal at 1000°C. For Cl and Mn ions, the concentration distributions became narrower when annealed at high temperatures.

• Periodical: Defect and Diffusion Forum (Volume 264)
• Pages: 7-12
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.264.7
• Online since: April 2007
• Authors: F. Salman, J. Arnold, Peng Zhang, Guan Gyu Chai, Fred A. Stevie, Lee Chow
• Keywords: Diffusion, Ion Implantation, Polycrystalline Silicon, Secondary Ion Mass Spectroscopy (SIMS)

References

[1] J.K. Rath, Solar Energy Materials & Solar Cells, 76, (2003), p.431.

[2] P. Woditsch and W. Koch, Solar Energy Materials & Solar Cells, 72 (2002), p.11.

[3] H. Puchner and S. Selberherr, IEEE Trans. Electron Devices, 42(10), (1995), p.1750.

[4] T.I. Kamins, J. Manoliu, and R.N. Tucker; J. Appl. Phys. 43, (1972), p.83.

[5] J.C.M. Hwang, P.S. Ho, J.E. Lewis, and D.R. Campbell; J. Appl. Phys. 51, (1980), p.1576.

[6] D. Demireva and B. Lammel, J. of Phys. D: Appl. Phys. 30, (1997), p. (1972).

[7] H.H. Tseng, M. Orlowski, P.J. Tobin, and R.L. Hance, Electron Device Letters, 13(1), (1992), p.14.

[8] T.P. Chen, T.F. Lei, C.Y. Chang, W.Y. Hsieh, and L.J. Chen, J. Electrochem. Soc. 142(6), (1995), p. (2000).

[9] S.H. Park, and D.K. Schroder; J. Appl. Phys. 78, (1995), p.801.

[10] S. Nakayama and T. Sakai, J. Appl. Phys. 79(8), (1996), p.4024.

[11] M.J. Mitchell, P. Ashburn, and P.L.F. Hemment, J. Appl. Phys., 92, (2002), p.6924.

[12] H. Francois-St-Cyr, E. Anoshikina, F. Stevie, L. Chow, K. Richardson, and D. Zhou, J. Vac. Sci. Technol. B, Vol. 19, (2001), p.1769.

[13] H. Francois-Saint-Cyr, F. Stevie, J. M. McKinley, K. Elshot, L. Chow, and K. Richardson, J. Appl. Physics, 94, (2003), p.7433.

DOI: 10.1063/1.1624487

[14] P. Zhang, F. Stevie, R. Vanfleet, R. Neelakantan, M. Klimov, D. Zhou, and L. Chow, J. Appl. Phys., 96, (2004) p.1053.

[15] Barret, Nix, Tetelman, The principles of Engineering materials, (1973), p.125.

[16] R. Madar, in Silicides: Fundamentals and Applications", Ed. L. Migilio and F. d, Heurle, Singapore, New Jersey, London, Hong Kong, World Scientific (2000), p.1.

[17] W.H. Wang, W. Bolse, C. Illgner, K.P. Lieb, J. Keinonen, and J. C. Ewert, Thin Solid Films, 295, (1997), p.169.

DOI: 10.1016/s0040-6090(96)09287-5

[18] R.N. Linnebach, J. Appl. Phys. 67(11), (1990), p.6794.

[19] A.H. von Ommem, J. Appl. Phys. 57, (1985) p.1872.

[20] A.H. von Ommem, J. Appl. Phys. 61, (1987) p.933.

[21] W.E. Beadle, J.C.C. Tsai, and R.D. Plummer, Quick Reference Manual for Silicon Integrated Circuit Technology (Wiley, New York, 1985), pp.6-31.

[22] V.P. Boldyrew, F.I. Prokovskii, S.G. Romanovskaro, A.V. Tkach, and I.E. Shimanovich, Sov. Phys. Semicond. 11, (1977), p.709.
