Optimization of Honeycomb Structures for Sandwich Panels by Response Surface Methodology (RSM)

Abstract:

This research aims to design and develop honeycomb structures for sandwich structures, focusing on enhancing the strength and reducing the weight of the components compared to the prototype. The research began with creating test models using a 3D printer and tensile testing with a Tensile Testing Machine. The data obtained from the tests were analyzed using SolidWorks software to adjust the material properties to align with the experimental results. The experimental design was conducted through the Response Surface Methodology (RSM), resulting in nine test model designs. These models were fabricated using a 3D printer, and their strength was analyzed with SolidWorks and validated through tensile testing. The experimental results revealed that six models exhibited a 133.655% increase in strength and a 7.568% reduction in weight compared to the prototype.

• Periodical: Key Engineering Materials (Volume 1029)
• Pages: 55-60
• DOI: https://doi.org/10.4028/p-Dktd1q
• Online since: November 2025
• Authors: Wannalak Laotaweesub, Kanlaya Ubontip, Patpimol Suwankan*, Sumethinee Hoochaiyaphum
• Keywords: Honeycomb Structures, Lightweight High-Strength Structures, Response Surface Methodology (RSM), Sandwich Structures, Tensile Testing

References

[1] Bitzer, T., 1997. Honeycomb technology [electronic resource]: materials, design, manufacturing, applications and testing. Dordrecht: Springer.

[2] Pflug, J. and Verpoest, I., 2004. Thermoplastic folded honeycomb structure and method for the production thereof. World Patent Application WO 00/32382.

[3] Fischer, S., et al., 2009. Mechanical tests for fold core base material properties. Composites Part A: Applied Science and Manufacturing, 40 (12), 1941–1952.

DOI: 10.1016/j.compositesa.2009.03.005

[4] Bournazel, J. and Ducruy, G., 1987. Method and applications for the extrusion of thermoplastic honeycomb structure, and structures thus obtained. International Patent Application WO 87/00119.

[5] Chunjin Li, Jiamei Zhu, Junlan Guo, and Qiang He heqiang, 2025. Vibration and acoustic characteristics of novel auxetic honeycomb sandwich panels with polyurea-metal laminate face sheets. Journal of Sandwich Structures & Materials.

DOI: 10.1177/10996362251323425

[6] Nygaard, J.V. and Lyckegaard, A., 2007. Sandwich beam with a periodical and graded core manufactured using rapid prototyping. Journal of Sandwich Structures and Materials, Volume 9, Issue 4, 365–376.

DOI: 10.1177/1099636207071609

[7] Hou, Y., et al., 2013. The bending and failure of sandwich structures with auxetic gradient cellular cores. Composites Part A: Applied Science and Manufacturing, 49, 119–131.

DOI: 10.1016/j.compositesa.2013.02.007

[8] Singh, R., Singh, V., and Saini, M. S., 2010. Experimental investigations for statistically controlled rapid moulding solution of plastics using polyjet printing. ASME conference proceedings, 12–18 November 2010, British Columbia, Canada: Vancouver, 1049–1053.

DOI: 10.1115/imece2010-37047

[9] Yeong, W.-Y., et al., 2005. Development of scaffolds for tissue engineering using a 3D inkjet model maker. In: P.J. Bártolo et al., ed. Virtual modelling and rapid manufacturing. London: Taylor & Francis, 115–118.

[10] Ibrahim, D., et al., 2009. Dimensional error of selective laser sintering, threedimensional printing and PolyJet™ models in the reproduction of mandibular anatomy. Journal of Cranio-Maxillofacial Surgery, 37 (3), 167–173. doi:10. 1016/j.jcms.2008.10.008.

DOI: 10.1016/j.jcms.2008.10.008

[11] Chua, C.K. and Leong, K.F., 2014. 3D printing and additive manufacturing: principles and applications fourth edition of rapid prototyping. 4th ed. Singapore: World Scientific.

DOI: 10.1142/9008
