Design and Simulation of a DETF for Use in a Resonant Gyroscope

Abstract:

The principle of operation of double-ended resonant tuning forks (DETF) is described in this paper. A new kind of DETF used in the resonant gyroscope is proposed. Considering the feasibility of fabrication, the dimensions are optimized. The variation of the natural frequency against the force applied to one end of the DETF is discussed. The relation between the driving modal frequency of resonant gyroscope and the driving modal frequency of DETF is analyzed.

• Periodical: Key Engineering Materials (Volumes 295-296)
• Pages: 113-118
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.295-296.113
• Online since: October 2005
• Authors: Yi Lun Zhu, S.R. Wang, A.P. Qiu
• Keywords: DETF, Frequency Modulation, Frequency Shifts, MEMS Gyroscope, Resonator

References

[1] A.A. Seshia, R.T. Howe and S. Montague: Proc of the 15 th IEEE Micro Electro Mechanical Systems Conference, Las Vegas, (2002).

[2] A.A. Seshia, T.A. Roessig and R.T. Howe: Journal of Microelectromechanical Systems, Vol. 11, (2002).

[3] T.A. Roessig, R.T. Howe and A.P. Pisano: IEEE International Frequency Control Symposium, (1997).

[4] C.T.C. Nguyen: IEEE Ultrasonics Symposium, 1995, p.489.

[5] C. Harris and C. Crede: Shock and Vibration Handbook (McGraw Hill, 1976).
