Numerical Optimization Approach of the Gap between the Magnet and Coil for Electromagnetic Vibration Energy Harvesters Design

Abstract:

In the design of the micro electromagnetic vibration harvester, an important goal is maximization of the magnetic flux linkage gradient, which directly determines the induced voltage and output power of the electromagnetic vibration harvester. This paper established a numerical model based on structure of the electromagnetic vibration energy harvester. An analytic expression for the magnetic field of rectangular permanent magnets is used to build up an electromagnetic coupling model. The magnetic field distribution of the rectangular permanent magnet was analyzed. The effects of the gap between the magnet and the coil on the load voltage of the electromagnetic vibration energy harvester were investigated. According to the formula, the magnetic flux linkage and flux gradient were calculated to optimize the geometrical parameter of the magnet and coil. The method and boundary conditions of optimizing the gap between the magnet and coil were presented. The maximum output voltage can be obtained by optimizing the gap between the magnet and the coil. A simple prototype was fabricated and measured to validate the theoretical deducing and the feasibility of method.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 1214-1222
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.1214
• Online since: May 2015
• Authors: Yi Ming Lei*, Zhi Yu Wen
• Keywords: Electromagnetic Damping Coefficient, Magnetic Flux Linkage Gradient, Vibration Energy Harvesting

References

[1] S. Roundy, P. k. Wright, J. Rabaey, A study of low level vibrations as a power source for wireless sensor nodes, Solar Cells 26(2003) 1131-1144.

DOI: 10.1016/s0140-3664(02)00248-7

[2] Hakan Toreyin, Emre Topal, Haluk Kulah, A multi-source micro power generator employing thermal and vibrtion energy harvesting, Procedia Engineering 5(2010) 1176-1179.

DOI: 10.1016/j.proeng.2010.09.321

[3] Rashed H. Bhuigyn, Roger A. Dougal and Mohannmod Ali, A miniature energy harvesting device for wireless sensor in elelctric power system, Sensors Journal (2010), Vol. 10, NO. 7.

[4] E. Sardini, M. Balsi, An efficient electromagnetic power harvesting device for low-frequency applications, Sensors and Actuators A: Physical 172 (2011) 475-482.

DOI: 10.1016/j.sna.2011.09.013

[5] S. P. Beeby, M. J. Tudor, and N. M. White, Energy harvesting vibration sources for micro-systems applications [J]. Measurement science and technology, Vol. 17, no. 12, pp. R175–R195, (2006).

DOI: 10.1088/0957-0233/17/12/r01

[6] Tom J. Kazmierki, Leran Wang, Bashir M. Al-Hashimi and Geoff V. Merrett, An explocit linearized state-space technique for accelerated simulation of electromagnetic vibration energy harvesters Transactions in computer-aided design of integrated circuits and system, Vol. 31, NO. 4.

DOI: 10.1109/tcad.2011.2176124

[7] S. Kulkarni, E. Koukharenko, R. Torah, J. Tudor, S. Beeby, T. O' Donnell, and S. Roy, Design, fabrication and test of integrated micro scale vibration-based electromagnetic generator, Sensors and Actuators A, vol. 145-146, pp.336-342, July-August, (2008).

DOI: 10.1016/j.sna.2007.09.014

[8] Arnold DP. Review of micro scale magnetic power generation [J]. IEEE Trans. Magnetics (2007), 43(11): 3940-3951.

DOI: 10.1109/tmag.2007.906150

[9] C .B. Williams, and R. B. Yates, Analysis of a micro electric generator for micro-systems, Sensors and Actuators A, vol. 52, pp.8-11, (1996).

[10] D. Spreemann, D. Hoffmann, B. Folkmer, Y. Manoli. Numerical optimization approach for resonant electromagnetic vibration transducer designed for random vibration [J]. Micromechanics and Micro-engineering, 2008, 104001(8): 46-57.

DOI: 10.1088/0960-1317/18/10/104001

[11] C. Cepnik, O. Radler, S. Rosenbaum, T. Strohla, U. wallrabe. Effective optimization of electromagnetic energy harvesters through direct computation of the electromagnetic coupling[J]. Sensors and Actuators A: Physical, 2011, 416-421.

DOI: 10.1016/j.sna.2011.01.023
