Micromachined Tri-Axis Capacitive Accelerometer Based on the Single Mass

Abstract:

A novel micromachined tri-axis capacitive accelerometer based on the single mass is proposed in this paper. The presented accelerometer contains a single proof mass acting as the sensitive element which is suspended by two flexible beams above the substrate, and an array of movable and fixed electrodes is utilized. To match the sensitivity design requirement, the differential capacitive detection is utilized, and the cross-sensitivity problem of three orthogonal axes is avoided ideally. The accelerometer structure is based on the EPI-poly process to realize the 18 microns thickness. Thus the detection capacitance, sensitivity and reliability are improved, the mechanical noise is decreased. To reduce the thermomechanical stress’ effect on the offset, a special anchor-middle structure is designed. Simulation results show that the offset is insensitive to the thermomechanical stresses and the sensor has a good consistency in three axes which has been validated by the testing results.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 630-635
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.630
• Online since: May 2015
• Authors: Fei Yuan, Li Guo Chen*, Tao Chen, Li Ning Sun
• Keywords: Cross Sensitivity, Differential Capacitance, MEMS, Single Proof Mass, Thermomechanical Stress, Tri-Axis Accelerometer

References

[1] Kuehnel W. Modelling of the mechanical behaviour of a differential capacitor acceleration sensor[J]. Sensors and Actuators A: Physical, 1995, 48(2): 101-108.

DOI: 10.1016/0924-4247(94)00983-o

[2] Zhang X, Park S, Judy M W. Accurate assessment of packaging stress effects on mems sensors by measurement and sensor–package interaction simulations[J]. Microelectromechanical Systems, Journal of, 2007, 16(3): 639-649.

DOI: 10.1109/jmems.2007.897088

[3] Serrano-Vázquez F X, Herrera-May A L, Bandala-Sánchez M. Design and modeling of a single-mass biaxial capacitive accelerometer based on the SUMMiT V process[J]. Microsystem technologies, 2013, 19(12): 1997-(2009).

DOI: 10.1007/s00542-013-1852-6

[4] Li B, Lu D, Wang W. Micromachined accelerometer with area-changed capacitance[J]. Mechatronics, 2001, 11(7): 811-819.

DOI: 10.1016/s0957-4158(00)00050-7

[5] Xie J, Agarwal R, Liu Y, et al. A three-axis SOI accelerometer sensing with both in-plane and vertical comb electrodes[J]. Microsystem technologies, 2012, 18(3): 325-332.

DOI: 10.1007/s00542-011-1393-9

[6] Qu W, Wenzel C, Gerlach G. Fabrication of a 3D differential-capacitive acceleration sensor by UV-LIGA[J]. Sensors and Actuators A: Physical, 1999, 77(1): 14-20.

DOI: 10.1016/s0924-4247(98)00377-x

[7] Nonomura Y, Omura Y, Funabashi H, et al. Chip-Level Warp Control of SOI 3-Axis Accelerometer with the Zigzag-Shaped Z-Electrode [J]. Procedia Engineering, 2012, 47: 546-549.

DOI: 10.1016/j.proeng.2012.09.205

[8] Hollocher D, Zhang X, Sparks A, et al. A very low cost 3-axis MEMS accelerometer for consumer applications[C]. Sensors 2009 IEEE, 2009: 953-957.
