Noise Analysis of Silicon Microgyroscope's Transimpedance Amplifier Interface Circuit

Abstract:

The output-current of silicon microgyroscope is at the level of 10^-7A. So the requirements for circuits’ SNR are very high. This paper proposes a method to improve transimpedance amplifier interface circuit’s SNR. First of all, the operating principles of silicon microgyroscope and transimpedance amplifier interface circuit are introduced. Secondly, resistor thermal noise, amplifier’s current and voltage noise are analyzed. Then noise density in a certain frequency range is calculated based on Matlab. Besides, a method to improve SNR is proposed, namely, increasing the value of DC offset resistance. Finally, simulation based on Cadence is operated to verify the method. Simulation results fit well with the theoretical analysis. That means the method to improve the SNR is feasible.

• Periodical: Key Engineering Materials (Volumes 645-646)
• Pages: 624-629
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.645-646.624
• Online since: May 2015
• Authors: Wei Feng Tang*, An Ping Qiu, Guo Ming Xia, Yan Su
• Keywords: Interface Circuit, Noise Analysis, Silicon Microgyroscope, Transimpedance

References

[1] Jun Liu, Yunbo Shi, Jie Li: submitted to Journal of Micro-inertial Technology. (2005).

[2] Qin Shi: Study on Key Technologies of Silicon Microgyroscopes for Improving Performance[D]. 2005. (in Chinses).

[3] Anping Qiu, Qin Shi, Yan Su: China ZL200710133223. 5[P]. 2008-03-05. (in Chinses).

[4] Analog Devices. http: /www. analog. com[OL].

[5] Jinzhan Gao: Detection of weak signals[M]. Tsinghua university press, 2004, p.56. (in Chinese).
