Enhancement of Voltammetric Signals Using a Graphene Oxide Modified Carbon Electrode for Electrochemical Paper-Based Analytical Devices

Abstract:

This work presents an enhancement of the voltammetric signal on an electrochemical paper-based analytical device (ePAD) using a graphene oxide (GO) modified carbon electrode. The ePAD is fabricated using a screen printing technique for fabrication of the hydrophobic area and three electrode strips. The graphene film was directly prepared on ePAD by dropping 2 µL of GO dispersed in water onto the working electrode surface and leaving it to dry at room temperature. The electrochemical reduction process of GO was carried out by applying a constant voltage of -1.20 V (vs. Ag/AgCl electrode strip) in 0.1 M KCl for 800 s. The GO-modified carbon working electrode on ePAD was readily obtained and ready to use after removing KCl solution. We tested the enhancement of the voltammetric signal on ePAD with a 6 mM [Fe(CN)₆]^4–/3– redox couple in 0.1 M KCl supporting electrolyte solution. Our results obtained from cyclic voltammograms showed that the unmodified working electrode and the GO-modified working electrode on ePAD provided similar anodic and cathodic peaks. Due to accelerated electron transfer process, it was found that the GO-modified working electrode on ePAD provided approximately a 2-fold increase in voltammetric signals when compared to the unmodified working electrode on ePAD. The reproducibility (inter-day precision) of the voltammetric signal measurement using a GO-modified working electrode on ePAD was acceptable. The relative standard deviation (RSD) was 5-8%. Therefore, the GO-modified carbon working electrode on ePAD offers an effective approach to enhance the signal and sensitivity for chemical analysis.

• Periodical: Key Engineering Materials (Volume 824)
• Pages: 197-203
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.824.197
• Online since: October 2019
• Authors: Kitima Sirivibulkovit, Thitaree Pimklang, Pasit Pakawatpanurut, Akhmad Sabarudin, Duangjai Nacapricha, Phoonthawee Saetear*
• Keywords: Electrochemical Paper-Based Device, ePAD, Graphene Oxide, Voltammetry

References

[1] M. Pumera, A. Ambrosi, A. Bonanni, E.L.K. Chng, H.L. Poh, Graphene for electrochemical sensing and biosensing, TrAC. 29(9) (2010) 954-965.

DOI: 10.1016/j.trac.2010.05.011

[2] D.A.C. Brownson, G.C. Smith, C.E. Banks, Graphene oxide electrochemistry: the electrochemistry of graphene oxide modified electrodes reveals coverage dependent beneficial electrocatalysis, R. Soc. Open. Sci. 4(11) (2017) 171128.

DOI: 10.1098/rsos.171128

[3] E. Bourgeat-Lami, J. Faucheu, A. Noël, Latex routes to graphene-based nanocomposites, Polym. Chem. 6(30) (2015) 5323-5357.

DOI: 10.1039/c5py00490j

[4] A. Ambrosi, C.K. Chua, N.M. Latiff, A.H. Loo, C.H. Wong, A.Y. Eng, A. Bonanni, M. Pumera, Graphene and its electrochemistry - an update, Chem. Soc. Rev. 45(9) (2016) 2458-2493.

DOI: 10.1039/c6cs00136j

[5] Y. Shao, J. Wang, M. Engelhard, C. Wang, Y. Lin, Facile and controllable electrochemical reduction of graphene oxide and its applications, J. Mater. Chem. 20(4) (2010) 743-748.

DOI: 10.1039/b917975e

[6] C.M. Moreira, S.V. Pereira, J. Raba, F.A. Bertolino, G.A. Messina, Paper-based enzymatic platform coupled to screen printed graphene-modified electrode for the fast neonatal screening of phenylketonuria, Clin Chim Acta. 486 (2018) 59-65.

DOI: 10.1016/j.cca.2018.07.016

[7] J. Ping, Y. Wang, K. Fan, J. Wu, Y. Ying, Direct electrochemical reduction of graphene oxide on ionic liquid doped screen-printed electrode and its electrochemical biosensing application, Biosens Bioelectron. 28(1) (2011) 204-209.

DOI: 10.1016/j.bios.2011.07.018

[8] M.L. Scala-Benuzzi, J. Raba, G. Soler-Illia, R.J. Schneider, G.A. Messina, Novel Electrochemical Paper-Based Immunocapture Assay for the Quantitative Determination of Ethinylestradiol in Water Samples, Anal. Chem. 90(6) (2018) 4104-4111.

DOI: 10.1021/acs.analchem.8b00028

[9] B. Wei, K. Mao, N. Liu, M. Zhang, Z. Yang, Graphene nanocomposites modified electrochemical aptamer sensor for rapid and highly sensitive detection of prostate specific antigen, Biosens Bioelectron. 121 (2018) 41-46.

DOI: 10.1016/j.bios.2018.08.067

[10] Q. Kong, Y. Wang, L. Zhang, C. Xu, J. Yu, Highly sensitive microfluidic paper-based photoelectrochemical sensing platform based on reversible photo-oxidation products and morphology-preferable multi-plate ZnO nanoflowers, Biosens Bioelectron. 110 (2018) 58-64.

DOI: 10.1016/j.bios.2018.06.026

[11] Y. Wu, P. Xue, Y. Kang, K.M. Hui, Paper-based microfluidic electrochemical immunodevice integrated with nanobioprobes onto graphene film for ultrasensitive multiplexed detection of cancer biomarkers, Anal. Chem. 85(18) (2013) 8661-8668.

DOI: 10.1021/ac401445a

[12] Y.H. Ngo, D. Li, G.P. Simon, G. Garnier, Paper surfaces functionalized by nanoparticles, Adv. Colloid Interface Sci. 163(1) (2011) 23-38.

DOI: 10.1016/j.cis.2011.01.004

[13] J. William S. Hummers, Richard E. Offeman, Preparation of Graphitic Oxide, J. Am. Chem. Soc. 80(6) (1958) 1339–1339.

DOI: 10.1021/ja01539a017
