Experimental Study of Switching and Short-Circuit Performance of 1.2 kV 4H-SiC Accumulation and Inversion Channel Power MOSFETs

Abstract:

This paper compares the static and dynamic performance of 1.2 kV 4H-SiC ACCUFETs and INVFETs with identical channel length (0.5 μm) and gate oxide thickness (55 nm). It is demonstrated for the first time that ACCUFETs have lower total switching losses in comparison to the INVFETs. ACCUFETs are therefore superior devices for applications due to their lower specific on-resistance and overall switching losses. However, short circuit tests conducted on the devices show that ACCUFETs have a smaller short-circuit time (t_SC) in comparison the INVFETs due to their higher short-circuit current.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2019

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1004)

Pages:

789-794

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.1004.789

Citation:

Cite this paper

Online since:

July 2020

Authors:

Aditi Agarwal*, Ajit Kanale, Ki Jeong Han, B. Jayant Baliga, Subhashish Bhattacharya

Keywords:

ACCUFET, Double Pulse Test (DPT), High-Frequency Figure-of-Merit (HF-FOM), INVFET, Saturation Current, Short Circuit Test

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] B. J. Baliga, U.S. Patent 5,543,637, issued August 6, (1996).

Google Scholar

[2] P. M. Shenoy and B. J. Baliga, The planar 6H-SiC ACCUFET: a new high-voltage power MOSFET structure, IEEE Electron Device Lett. 18 (1997) 589–591.

DOI: 10.1109/55.644080

Google Scholar

[3] W. Sung, K. Han, and B. J. Baliga, A comparative study of channel designs for SiC MOSFETs: Accumulation mode channel vs. inversion mode channel, 29th IEEE ISPSD (2017) 375–378.

DOI: 10.23919/ispsd.2017.7988996

Google Scholar

[4] B. J. Baliga, W. J. Sung, K. J. Han, J. Harmon, A. Tucker, and S. Syed, PRESiCETM: Process Engineered for Manufacturing SiC Electronic Devices, Mater. Sci. Forum, 924 (2018) 523–526.

DOI: 10.4028/www.scientific.net/msf.924.523

Google Scholar

[5] B. J. Baliga, Gallium Nitride and Silicon Carbide Power Devices, World Scientific, New Jersey, 2016, pp.312-313.

Google Scholar

[6] B. J. Baliga, Fundamentals of Power Semiconductor Devices, Second Edition, Springer, Cham, Switzerland, (2019).

Google Scholar

[7] A. Kanale and B. J. Baliga, Enhancing Short Circuit Capability of 1.2 kV SiC Power MOSFETs using a Gate-Source Shorted Si Depletion Mode MOSFET in Series with the Source, PEDS (2019) Paper 827.

DOI: 10.1109/peds44367.2019.8998921

Google Scholar

[8] S. Hazra, K. Vechalapu, S. Madhusoodhanan, S. Bhattacharya and K. Hatua, Gate Driver Design Considerations for Silicon Carbide MOSFETs Including Series Connected Devices, ECCE (2017) p.1402–1409.

DOI: 10.1109/ecce.2017.8095954

Google Scholar
