Multi-Scale Characterization by Neutronography and Electron Diffraction of Ni Coating on Cu-Ni-Al or Cast-Iron Glass Molds after Laser Cladding

Abstract:

Laser cladding of a Ni based powder on Cu-Ni-Al or cast iron was performed with a 4kW continuous Nd: YAG laser. The Cu-Ni-Al and cast-iron substrates are used for their thermal properties in glass mold industry. But the issue of these materials is their lack of resistance on corrosion and abrasion. The role of the Ni based alloy is to protect the mold without affecting its thermal properties (Heat Affected Zone (HAZ)). The purpose of this research is to produce a well bonded Ni based melted powder without pores or cracks on a non-planar surface (curvilinear section). An investigation of the impact of the processing parameters, power (1500-3200 W), scanning speed (2.5-10 mm/s) and powder feeding rate (24.5-32.5 g/min) on the bonding quality, the porosity propagation and HAZ appearance is performed. The used methods are neutronography, Scanning Electron Microscopy, Energy Dispersive Spectroscopy and Electron BackScatter Diffraction (EBSD). These multi-scale techniques are obviously complementary. Neutronography is a well-adapted non-destructive method to observe the porosity in the volume thanks to the contrast between materials. EBSD analysis allows us to analyze the microstructural evolution of the coating notably by observing the dendrites growth. This same method also permits to observe the HAZ nature according to the laser cladding parameters. Those methods allowed to optimize the processing parameters in a way to obtain perfect bonding, to avoid porosity propagation and to limit the HAZ emergence.

• Periodical: Materials Science Forum (Volume 1016)
• Pages: 297-302
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1016.297
• Online since: January 2021
• Authors: Fazati Bourahima*, Anne Laure Helbert, Frédéric Ott, Vincent Ji, Michel Rege, François Brisset, Arnaud Courteaux, Thierry Baudin
• Keywords: Laser Cladding, MEB/EDS/EBSD, Multi-Scale Analysis, Neutronography

References

[1] T. DebRoy, H.L. Wei, J.S. Zuback, T. Mukherjee, J.W. Elmer, J.O. Milewski, A.M. Beese, A. Wilson-Heid, A. De, W. Zhang, Additive manufacturing of metallic components – Process, structure and properties, Prog. Mater. Sci. 92 (2018) 112–224.

DOI: 10.1016/j.pmatsci.2017.10.001

[2] M. Rege, S. Van Linden, Stage de formation aux techniques de rechargement dans l'industrie verrière, Marcoussis, (2016).

[3] F. Bourahima, A.L. Helbert, M. Rege, V. Ji, D. Solas, T. Baudin, Laser cladding of Ni based powder on a Cu-Ni-Al glassmold: Influence of the process parameters on bonding quality and coating geometry, J. Alloys Compd. 771 (2019) 1018–1028.

DOI: 10.1016/j.jallcom.2018.09.004

[4] G. Xu, M. Kutsuna, Z. Liu, K. Yamada, Comparison between diode laser and TIG cladding of Co-based alloys on the SUS403 stainless steel, Surf. Coatings Technol. 201 (2006) 1138–1144.

DOI: 10.1016/j.surfcoat.2006.01.040

[5] H. Liu, J. Hao, Z. Han, G. Yu, X. He, H. Yang, Microstructural evolution and bonding characteristic in multi-layer laser cladding of NiCoCr alloy on compacted graphite cast iron, J. Mater. Process. Technol. 232 (2016) 153–164.

DOI: 10.1016/j.jmatprotec.2016.02.001

[6] F. Fu, Y. Zhang, G. Chang, J. Dai, Analysis on the physical mechanism of laser cladding crack and its influence factors, Optik (Stuttg). 127 (2016) 200–202.

DOI: 10.1016/j.ijleo.2015.10.043

[7] P. Yi, X. Zhan, Q. He, Y. Liu, P. Xu, P. Xiao, D. Jia, Influence of laser parameters on graphite morphology in the bonding zone and process optimization in gray cast iron laser cladding, Opt. Laser Technol. 109 (2019) 480–487.

DOI: 10.1016/j.optlastec.2018.08.028

[8] G. Pépy, Spectrométrie masse - principe neutrons - analyse et appareillage par : les faisceaux de neutrons analyse des traces , imagerie et médecine, Tech. l'ingénieur. V1 (2006) 1–8.

DOI: 10.51257/a-v1-bn3016

[9] C. Thiery, Tomographie à rayons X, Tech. l'ingénieur. P950 V3 (2013) 1–30.

[10] F. Bourahima, Évolutions microstructurales et défauts générés par laser cladding lors du dépôt de Ni sur des moules de verrerie en alliage de Cu-Ni-Al et en fonte GL, Thèse Université Paris-Sud, To cite this version : HAL Id : tel-02044203, (2019).

[11] DRSN/SEROS, http://www-llb.cea.fr/neutrono/radio-neut.html, (2016). http://www-llb.cea.fr/neutrono/radio-neut.html.
