Distinction of the Nuclei of Shockley Faults in 4H-SiC{0001} pin Diodes by Electroluminescence Imaging

Abstract:

We investigated the location of the nuclei of Shockley-type stacking faults (SSFs) in the 4H-SiC pin diodes, using electroluminescence (EL) imaging. The nuclei of SSFs were identified as three types, located (i) on the mesa edge, (ii) in the surface region, and (iii) inside the epilayer. We compared the frequency of the nuclei according to these three locations for the (0001) and (000-1) pin diodes. The number of SSFs originated from the nuclei inside the epilayer in the (000-1) pin diodes was much less (<4 cm-2) than that in the (0001) pin diodes. However, the numbers of SSF nuclei (0.3 ~ 0.8 per device) located on the mesa wall and the surface region in the (000-1) pin diodes were comparable to the (0001) pin diodes. We also investigated the process responsible for generating the SSF nuclei.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2006

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 556-557)

Pages:

251-254

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.556-557.251

Citation:

Cite this paper

Online since:

September 2007

Authors:

R. Ishii, Toshiyuki Miyanagi, Isaho Kamata, Hidekazu Tsuchida, Koji Nakayama, Yoshitaka Sugawara

Keywords:

Basal Plane Dislocation (BPD), Electroluminescence, Shockley-Type Stacking Faults

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Y. Sugawara: in Proceedings of the 15th International Symposium on Power Device & Ics (April 14-17, Cambridge, UK, 2003), p.10.

Google Scholar

[2] H. Lendemann, F. Dahlquist, J. P. Bergman, H. Bleihner and C. Hallin: Mater. Sci. Forum Vol. 389-393 (2002), p.1259.

Google Scholar

[3] J. J. Sumakeris, M. Das, H. McD. Hobgood, S.G. Müller, M. J. Paisley, S. Ha, M. Skowronski, J. W. Palmour and C. H. Carter, Jr.: Mater. Sci. Forum Vol. 457-460 (2004) p.1113.

DOI: 10.4028/www.scientific.net/msf.457-460.1113

Google Scholar

[4] H. Tsuchida, T. Miyanagi, I. Kamata, T. Nakamura, K. Nakayama, R. Ishii and Y. Sugawara: Jap. J. Appl. Phys. Vol. 44 (2005), p.806.

Google Scholar

[5] S. I. Maximenko and T. S. Sudarshan : J. Appl. Phys. 97, 074501 (2005).

Google Scholar

[6] N. Camara, A. Thuaire, E. Bano, K. Zekentes : Mater. Sci. Forum Vol. 483-485 (2005), p.773.

Google Scholar

[7] Y. Sugawara, K. Asano, R. Singh and J. W. Palmour: Mater. Sci. Forum Vol. 338-342 (2000), p.1371.

Google Scholar

[8] S. G. Sridhara, F. H. C. Carlsson, J. P. Bergman and E. Janzén : Appl. Phys. Lett. Vol. 79 No. 24 (2001), p.3944.

Google Scholar

[9] P. Pirouz, J. L. Demenet, and M. H. Hong: Philos. Mag. Vol. A 81 (2001), p.1207.

Google Scholar

[10] T. Miyanagi, H. Tsuchida, I. Kamata, T. Nakamura, K. Nakayama, R. Ishii and Y. Sugawara: Appl. Phys. Lett. Vol. 89 (2006), 062104.

DOI: 10.1063/1.2234740

Google Scholar
