Simulation of TEDREC Phenomena for 4H-SiC Pin Diode with p/n Type Drift Layer

Abstract:

Temperature dependence simulations of forward characteristics for 4H-SiC pin diodes with Shockley-type stacking faults are performed in order to investigate the mechanism of the TEDREC phenomena. The forward voltage drops of both n-type and p-type drift layers at room temperature increase as the length of the Shockley-type stacking fault increases. When the diodes are compared to each other at the same temperature, the differences between the forward voltage drops do not change significantly up to 150 oC, but the differences suddenly narrow in the range from 150 °C to 200 °C. The Shockley-type stacking fault prevents current from flowing at room temperature. The current, however, flows throughout the drifted diode when the temperature is raised.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2012

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 740-742)

Pages:

1107-1110

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.740-742.1107

Citation:

Cite this paper

Online since:

January 2013

Authors:

Koji Nakayama, Tetsuro Hemmi, Katsunori Asano

Keywords:

4H-SiC, N-Type Drift Layer, PiN Diode, P-Type Drift Layer, Shockley-Type Stacking Fault, TEDREC

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] H. Lendenmann, F. Dahlquist, N. Johansson, R. Soderholm, P. A. Nilsson, J. P. Bergman, and P. Skytt, Mater. Sci. Forum 353–356 (2001) 727.

DOI: 10.4028/www.scientific.net/msf.353-356.727

Google Scholar

[2] H. Tsuchida, I. Kamata, T. Miyanagi, T. Nakamura, K. Nakayama, R. Ishii1 and Y. Sugawara, Jpn. J. Appl. Phys., 44 (2005) 25, L 806.

Google Scholar

[3] H. Tsuchida, T. Miyanagi, I. Kamata, T. Nakamura, K. Izumi, K. Nakayama, R. Ishii, K. Asano and Y. Sugawara, Mater. Sci. Forum, 483-485 (2005) 97.

DOI: 10.4028/www.scientific.net/msf.483-485.97

Google Scholar

[4] J. J. Sumakeris, J. P. Bergman, M. K. Das, C. Hallin, B. A. Hull, E. Janzen, H. Lendenmann, M. J. O'Loughlin, M. J. Paisley, S. Ha, M. Skowronski, J. W. Palmour and C. H. Carter, Jr, Mater. Sci. Forum, 527-529 (2006) 141.

DOI: 10.4028/www.scientific.net/msf.527-529.141

Google Scholar

[5] Y. Sugawara, Y. Miyanagi, K. Nakayama, K. Asano, S. Ogata, T. Izumi and A. Tanaka, Proc. 19th Int. Symp. Power Semiconductor Devices & ICs (2007) 273.

DOI: 10.1109/ispsd.2007.4294985

Google Scholar

[6] U. Lindefelt, H. Iwata, S. Berg and P. R. Briddon, Physical Review B, 67 (2003) 155204.

Google Scholar

[7] K. Nakayama, Y. Sugawara, Y. Miyanagi, K. Asano, S. Ogata, S. Okada, T. Izumi and A. Tanaka, Mater. Sci. Forum, 600-603 (2009) 1175.

DOI: 10.4028/www.scientific.net/msf.600-603.1175

Google Scholar
