On-Axis Homoepitaxial Growth of 4H-SiC PiN Structure for High Power Applications

Abstract:

We demonstrate on-axis homoepitaxial growth of 4H-SiC(0001) PiN structure on 3-inch wafers with 100% 4H polytype in the epilayer excluding the edges. The layers were grown with a thickness of 105 µm and controlled n-type doping of 4 x 1014 cm-3.The epilayers were completely free of basal plane dislocations, in-grown stacking faults and other epitaxial defects, as required for 10 kV high power bipolar devices. Some part of the wafer had a lifetime enhancement procedure to increase lifetime to above 2 s using carbon implantation. An additional step of epilayer polishing was adapted to reduce surface roughness and implantation damage.

• Periodical: Materials Science Forum (Volumes 740-742)
• Pages: 173-176
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.740-742.173
• Online since: January 2013
• Authors: Jawad Hassan, Ian D. Booker, Louise Lilja, Anders Hallén, Martin Fagerlind, Peder Bergman, Erik Janzén
• Keywords: Carrier Lifetime, Chemical Vapor Deposition (CVD), Growth Mechanism, High Power Devices, On-Axis

References

[1] T. Ohno, H. Yamaguchi, S. Kuroda, K. Kojima, T. Suzuki, K. Arai, Direct observation of dislocations propagated from 4H-SiC substrate to epitaxial layer by X-ray topography, J Cryst. Growth, 260 (2004) 209-216.

DOI: 10.1016/j.jcrysgro.2003.08.065

[2] G. Feng, J. Suda, T. Kimoto, Characterization of major in-grown stacking faults in 4H-SiC epilayers, Physica B, 404 (2009) 4745-4748.

DOI: 10.1016/j.physb.2009.08.189

[3] P.B. Klein, R. Myers-Ward, K.K. Lew, B.L. VanMil, C.R. Eddy, D.K. Gaskill, A. Shrivastava, T.S. Sudarshan, Recombination processes controlling the carrier lifetime in n(-)4H-SiC epilayers with low Z(1/2) concentrations, J Appl Phys, 108 (2010).

DOI: 10.1063/1.3466745

[4] J. Hassan, J.P. Bergman, A. Henry, E. Janzen, On-axis homoepitaxial growth on Si-face 4H-SiC substrates, J Cryst Growth, 310 (2008) 4424-4429.

DOI: 10.1016/j.jcrysgro.2008.06.081

[5] S. Leone, H. Pedersen, A. Henry, O. Kordina, E. Janzen, Thick homoepitaxial layers grown on on-axis Si-face 6H-and 4H-SiC substrates with HCl addition, J Cryst Growth, 312 (2009) 24-32.

DOI: 10.1016/j.jcrysgro.2009.10.011

[6] J. Hassan, J.P. Bergman, Influence of structural defects on carrier lifetime in 4H-SiC epitaxial layers: Optical lifetime mapping, J Appl Phys, 105 (2009) 123518.

DOI: 10.1063/1.3147903

[7] L. Storasta, H. Tsuchida, Reduction of traps and improvement of carrier lifetime in 4H-SiC epilayers by ion implantation, Appl Phys Lett, 90 (2007) 062116-062118.

DOI: 10.1063/1.2472530
