Growth of (0001) AlN Single Crystals Using Carbon-Face SiC as Seeds

Abstract:

Growth of AlN single crystals using carbon-polar surface of SiC substrate by PVT growth method has been attempted. AlN growth on the carbon-face was dominated by spiral growth mode under the applied experimental conditions and further, an abrupt interface was observed between AlN layer and the substrate. Broad XRD rocking curve of the sample, taken from bottom part of the crystal, indicates a high density of misfit dislocations near the interface and further a shift of E₂(high) phonon mode in the Raman measurements shows a significant misfit stress. The XRD-RC FWHM values of symmetric 002 and asymmetric 102 reflections (top part of the crystal) are 380 and 300 arcsec respectively, whereas the Raman E₂(high) peak FWHM value is about 23 cm^-1. Decreasing intensity of silicon and carbon LVM peaks with increasing distance from the interface represents the reduction of their incorporation along the crystal length. EPMA analysis confirms the presence of low silicon concentration of 2 wt% in these crystals grown hetero-epitaxially on SiC.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2012

View Preview

Info:

Periodical:

Materials Science Forum (Volumes 740-742)

Pages:

99-102

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.740-742.99

Citation:

Cite this paper

Online since:

January 2013

Authors:

Rajappan Radhakrishnan Sumathi, Matthias Paun

Keywords:

Aluminum Nitride (AlN), C-Face, Inversion Domains, N-Polar, Silicon Carbide (SiC), Single Crystal

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] M. Stutzmann, O. Ambacher, M. Eickhoff, U. Karrer, A. Kima Pimenta, R. Neuberger et al., Playing with Polarity, Phys. Status Solidi B 228 (2001) 505-512.

DOI: 10.1002/1521-3951(200111)228:2<505::aid-pssb505>3.0.co;2-u

Google Scholar

[2] P. Lu, J.H. Edgar, C. Cao, K. Hohn, R. Dalmau, R. Schlesser, Z. Sitar, Seeded growth of AlN on SiC substrates and defect characterisation, J. Crystal Growth 310 (2008) 2462-2470.

DOI: 10.1016/j.jcrysgro.2008.01.010

Google Scholar

[3] R.R. Sumathi, P. Gille, Sublimation growth of c-plane AlN single crystals on SiC substrates, Cryst. Res. Technol. 47 (2012) 237-246.

DOI: 10.1002/crat.201100486

Google Scholar

[4] T. Prokofyeva, M. Seon, J. Vanbuskirk, M. Holtz, S.A. Nikishin, N.N. Faleev, H. Temkin, S. Zollner, Vibrational properties of AlN grown on (111)-oriented silicon, Phys. Rev. B 63 (2001) 125313 1-7.

DOI: 10.1103/physrevb.63.125313

Google Scholar

[5] M. G. Gomez, A. Cros, M. Hermann, M. Stutzmann, M. Eickhoff, Strain effects and phonon-plasmon coupled modes in Si-doped AlN, Phys. Status Solidi A 206 (2009) 1183-1186.

DOI: 10.1002/pssa.200880852

Google Scholar
