Organic/Inorganic Hybrid Materials for Organic Electronic Application

Abstract:

Organic/inorganic stacks were deposited on flexible polycarbonate substrate using inductively coupled plasma chemical vapor deposition (ICP-PECVD) for permeation barrier application. The effects of deposition temperature, RF power, gas flow ratio, deposition pressure on film properties of surface roughness, water vapor transmission rate (WVRT) were investigated. Energy dispersive spectrum (EDS), atomic force microscopy (AFM) and transmission electron microscopy (TEM) were used to characterize the film characteristics of the stack layers. It was found that the surface roughness Ra was as low as is 0.25 nm. The WVRT values of the optimum barriers structures were 10^-2g/m² day (1 pair of stacks) and 4.8 x 10^-5g/m² day (4 pair of stacks). This result indicated that the permeation barrier films prepared by ICP-PECVD could be a promising candidate for flexible electronic applications.

• Periodical: Materials Science Forum (Volume 848)
• Pages: 435-439
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.848.435
• Online since: March 2016
• Authors: Jian Liu, Jie Liu, Xing Long Leng, Fu Rong Qu
• Keywords: Encapsulation, Organic Electronic, Organic/Inorganic Alternative Structure, PECVD

References

[1] www. IDTechEx. com.

[2] Lewis, J. S.; Weaver, M. S., Thin-film permeation-barrier technology for flexible organic light-emitting devices. Ieee Journal of Selected Topics in Quantum Electronics 2004, 10, (1), 45-57.

DOI: 10.1109/jstqe.2004.824072

[3] Aziz, H.; Popovic, Z.; Xie, S.; Hor, A. M.; Hu, N. X.; Tripp, C.; Xu, G., Humidity-induced crystallization of tris (8-hydroxyquinoline) aluminum layers in organic light-emitting devices. Applied Physics Letters 1998, 72, (7), 756-758.

DOI: 10.1063/1.120867

[4] Leterrier, Y., Durability of nanosized oxygen-barrier coatings on polymers - Internal stresses. Progress in materials science 2003, 48, (1), 1-55.

DOI: 10.1016/s0079-6425(02)00002-6

[5] Sobrinho, A. S. D.; Latreche, M.; Czeremuszkin, G.; Klemberg-Sapieha, J. E.; Wertheimer, M. R., Transparent barrier coatings on polyethylene terephthalate by single- and dual-frequency plasma-enhanced chemical vapor deposition. Journal of Vacuum Science & Technology a-Vacuum Surfaces and Films 1998, 16, (6), 3190-3198.

DOI: 10.1116/1.581519

[6] Potscavage, W. J.; Yoo, S.; Domercq, B.; Kippelen, B., Encapsulation of pentacene/C-60 organic solar cells with Al2O3 deposited by atomic layer deposition. Applied Physics Letters 2007, 90, (25).

DOI: 10.1063/1.2751108

[7] Yoo, S.; Potscavage, W. J.; Domercq, B.; Han, S. H.; Li, T. D.; Jones, S. C.; Szoszkiewicz, R.; Levi, D.; Riedo, E.; Marder, S. R.; Kippelen, B., Analysis of improved photovoltaic properties of pentacene/C (60) organic solar cells: Effects of exciton blocking layer thickness and thermal annealing. Solid-State Electronics 2007, 51, (10), 1367-1375.

DOI: 10.1016/j.sse.2007.07.038

[8] Cros S, Firon M, Lenfant S, Trouslard P, Beck L (2006) Study of thin calcium electrode degradation by ion beam analysis. Nucl Instrum Methods Phys Res B 251: 257–260.

DOI: 10.1016/j.nimb.2006.06.014

[9] Lewis J, Grego S, Vick E, Temple D (2004) Performance of thin films for flexible OLED displays. 4th Annual Flexible Displays and Microelectronics Conference.

DOI: 10.1557/proc-814-i8.5

[10] G. Nisato, Proc. Soc. Info. Display Symp., Digest Tech. 2003, 34, 550.
