Newly Developed Switching Analysis Method for 3.3 kV 400 a Full SiC Module

Abstract:

We have demonstrated a new analysis method using a precise equivalent circuit of 3.3 kV 400 A full SiC modules and showed that the calculated waveforms well agree with the measured waveforms. We have also examined the current distribution in the module by utilizing this equivalent circuit model.
