3D Integration of Si-Based Peltier Device onto 4H-SiC Power Device

Abstract:

We propose 3-D integration of Peltier device onto a power device. In order to transport a heat from the power device, as a suitable material of the Peltier device, silicon was adopted because of its high Seebeck coefficient, high thermal conductivity, and applicability to semiconductor process. Bulk Si-based Peltier devices with conventional shape showed an active thermal transport over a Joule heat at the operation current less than 5 A. 3-D integration of 4H-SiC-based Schottky barrier diodes and Si-based film Peltier device, separated by intrinsic SiC layer, was realized by using conventional Si-based process flow.
