Utilization of SiC MOSFETs in Voltage Source Inverter of Inductive Power Transfer Systems for Enduring Capacitive Loads

Abstract:

In this work, the use of SiC MOSFETs is proposed for the implementation of the H-bridge Voltage Source Inverter (VSI) of Inductive Power Transfer Systems (IPTSs) in order to successfully support potential capacitive loading. Conventional power semiconductor devices are prevented from feeding capacitive loads because of the occurrence of current overshoots and voltage spikes due to the reverse recovery phenomenon of the antiparallel diodes. Operation of the VSI under capacitive load can be caused in IPTSs during resonant frequency tracking or misalignment between the coupled coils, due to the existence of resonant circuits. Experiments conducted with both Si and SiC MOSFETs show the superiority of the latter in terms of system stability, endurance in high power and avoidance of catastrophic failure.

• Periodical: Materials Science Forum (Volume 858)
• Pages: 1082-1086
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.858.1082
• Online since: May 2016
• Authors: Georgios Kampitsis*, Eleni Gati, Stavros Papathanassiou, Stefanos N. Manias
• Keywords: Capacitive Load, Inductive Power Transfer, Inverter, Over-Current, Reverse Recovery, SiC MOSFET

References

[1] R. Bosshard, U. Badstubner, J. W. Kolar and I. Stevanovic, Comparative evaluation of control methods for inductive power transfer, ICRERA (Nagasaki, 2012), p.1–6.

DOI: 10.1109/icrera.2012.6477400

[2] C. -Y. Huang, J. E. James and G. A. Covic, Design Considerations for Variable Coupling Lumped Coil Systems. IEEE Transactions on Power Electronics, vol. 30, no. 2, p.680–689 (2015).

DOI: 10.1109/tpel.2014.2311818

[3] E. Gati, G. Kampitsis, I. Stavropoulos, S. Papathanassiou and S. Manias, Wireless Phase - Locked Loop control for inductive Power Transfer Systems, APEC (Charlotte, NC, 2015), pp.1601-1607.

DOI: 10.1109/apec.2015.7104561

[4] H. Hao, G. A. Covic and J. T. Boys, An Approximate Dynamic Model of LCL-T-Based Inductive Power Transfer Power Supplies. IEEE Transactions on Power Electronics, vol. 29, no. 10, p.5554–5567 (2014).

DOI: 10.1109/tpel.2013.2293138

[5] R. Chen, C. Zheng, Z. U. Zahid, E. Faraci, W. Yu, J. Lai, M. Senesky, D. Anderson, G. Lisi: Analysis and parameters optimization of a contactless IPT system for EV charger, APEC 2014, pp.1654-1661.

DOI: 10.1109/apec.2014.6803528

[6] J. Liu, J. Mookken and K. L. Wong, Highly Efficient, and Compact ZVS Resonant Full Bridge Converter using 1200V SiC MOSFETs. PCIM Europe 2014, pp.1-8.

[7] V. Esteve, J. Jordan, E. Sanchis-Kilders et al., Comparative Study of a Single Inverter Bridge for Dual-Frequency Induction Heating Using Si and SiC MOSFETs. IEEE Transactions on Industrial Electronics, vol. 62, no 3, p.1440–1450 (2015).

DOI: 10.1109/tie.2014.2359411

[8] M. K. Kazimierczuk and D. Czarkowski, Resonant Power Converters. (John Willey & Sons Inc., 2011) p.189.

[9] P.G. Neudeck, Perimeter Governed Minority Carrier Lifetimes in 4H-SiC p(+)-n Diodes Measured by Reverse Recovery Switching Transient Analysis, J. Electron. Mater. 27, p.317–323, (1998).

DOI: 10.1007/s11664-998-0408-5

[10] Infineon Technologies, Primary Side MOSFET Selection for LLC Topology, Application Note, Revision1. 0, (2014).
