High-Temperature Transient Thermal Analysis for SiC Power Modules

Abstract:

Transient thermal analysis is a very useful tool for thermal evaluation to realize the stable operation of SiC power modules which are operated at higher temperatures than conventional Si power modules. A transient thermal analysis system to investigate the thermal characteristics of SiC power modules at high temperature is presented. We have found that precise temperature measurement at the initial stage of the junction temperature decay curve is necessary in order to evaluate the thermal resistance and heat capacity of the die attach, since the thermal diffusivity of SiC is larger than that of Si and the temperature distribution of SiC die was considered. Using the proposed transient thermal analysis method, the thermal resistance and heat capacity of the AuGe die attach under the SiC-SBD was successfully evaluated at temperatures up to 250 °C.

• Periodical: Materials Science Forum (Volume 858)
• Pages: 1078-1081
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.858.1078
• Online since: May 2016
• Authors: Fumiki Kato*, Hiroshi Nakagawa, Hiroshi Yamaguchi, Hiroshi Sato
• Keywords: Die Attach, Heat Capacity, High Temperature, SiC Power Module, Thermal Resistance, Transient Thermal Analysis

References

[1] K. Sasaki, S. Sato, K. Matsui, Y. Murakami, S. Tanimoto, and H. Tanisawa, 40 kW/L High Switching Frequency Three-Phase AC 400 V All-SiC Inverter, Mater. Sci. Forum, vol. 740–742, p.1081–1084 (2013).

DOI: 10.4028/www.scientific.net/msf.740-742.1081

[2] F. Kato, R. Simanjorang, F. Lang, H. Nakagawa, H. Yamaguchi, and H. Sato, 250°C-Operated sandwich-structured all-SiC power module, Jpn. J. Appl. Phys., 54, 04DP06 (2015).

DOI: 10.7567/jjap.54.04dp06

[3] T. Anzai, Y. Murakami, S. Sato, H. Tanisawa, K. Hiyama, H. Takahashi, F. Kato, and H. Sato, Sandwich Structured Power Module for High Temperature SiC Power Semiconductor Devices, IMAPS 2014 Proc., p.757–762 (2014).

DOI: 10.4071/isom-wp54

[4] C. Buttay, C. Raynaud, H. Morel, G. Civrac, M. L. Locatelli, and F. Morel, Thermal stability of silicon carbide power diodes, IEEE Trans. Electron Devices, vol. 59, no. 3, p.761–769 (2012).

DOI: 10.1109/ted.2011.2181390

[5] JEDEC standard, JESD51-14, Transient Dual Interface Test Method for the Measurement of the Thermal Resistance Junction to Case of Semiconductor Devices with Heat Flow Trough a Single Path, JEDEC Solid State Technology Association (Nov 2010).

DOI: 10.1109/stherm.2011.5767204

[6] M. Glavanovics, and M. Zitta, Thermal Destruction Testing: An Indirect Approach to a Simple Dynamic Model of Smart Power Switches, Proc. ESSIRC, pp.236-239 (2001).

[7] T. Hirata, M. Tanaka, and Y. Haneda, Den-netsu Kougaku, Morikita Publishing (2014).
