Accuracy of the Energy Distribution of the Interface States at the SiO₂/SiC Interface by Conductance Method

Abstract:

The electrical characteristics of the SiC metal-oxide-semiconductor field effect transistor (MOSFET) have been limited by large amount of states at the SiO₂/SiC interface. In this study, the accuracy of the energy level of the interface states extracted by hypothetical high frequency extreme, which is conventionally used, is experimentally examined. Conductance measurements at low temperature between 65 K and 100 K reveal that the extracted energy distribution of the interface states at nitrided SiO₂/SiC interface close to the conduction band edge depends on the measurement temperature. It is demonstrated that conductance method at 65K enables us more accurate evaluation of the interface states at the SiO₂/SiC interface and found that the interface states density (D_it) of nitride SiO₂/SiC interface is over 10¹³ cm^-2eV^-1 at energy level of 0.1 eV below the conduction band edge.
