The Behavior of Liquid Alloys Visualized by X-Rays

Abstract:

Developments in synchrotron and home laboratory X-ray sources and fast low noise X-ray imaging detectors over the last 15-20 years has enabled real time X-radiography of alloy solidification from the melt. These investigations have been an important tool for in–situ investigations of dendrite-, eutectic and monotectic growth, dendrite fragmentation etc. At the same time, the techniques have allowed studies of phenomena in the melt such as convection, formation of solute boundary layers and minority phase droplet interactions. The article will review the X-radiography techniques and some of the results with emphasis on studies of phenomena in alloy melts.

• Periodical: Materials Science Forum (Volume 884)
• Pages: 18-25
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.884.18
• Online since: January 2017
• Authors: Lars Arnberg*, Ragnvald H. Mathiesen
• Keywords: Alloys, Liquid Metal, Solidification, X-Radiography
