Research on the Springback of Square TA18 Titanium Alloy Tube on the Numerical Simulation

Abstract:

This paper focuses on how bending and springback process of the titanium tubes with different bending radius and bending angle affect the springback rate after unloading and analyses tube distributions and variations of stress and strain by establishing a three-dimensional elastic-plastic finite element model of square TA18 titanium alloy tube based on ABAQUS/explicit and ABAQUS/standard. It is shown that under the same process parameters, the sprignback rate obtained by numerical simulation is in good agreement with that measured in the experiments. The springback rate after unloading increases with the increase of the bending radius linearly, and it increases nonlinearly with the decrease of bending angle. The distribution of the tube-roundness and the relationship between its roundness and springback rate under different process parameters could be obtained by comparing the variation of the absolute value of its outer wall unit at the maximum principal strain before and after unloading.

• Periodical: Materials Science Forum (Volume 944)
• Pages: 753-760
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.944.753
• Online since: January 2019
• Authors: Cong Liu, Xiao Dong Yan*, Yin Yang, Wei Ye
• Keywords: Numerical Simulation, Roundness, Springback, TA18 Titanium Alloy, Tube Bending

References

[1] Jiang, Zhi Qiang, and X. U. Xu-Dong. State-of-the-arts and prospectives of manufacturing and application of titanium alloy tube in aviation industry., Journal of Plasticity Engineering 16.4(2009):44-46.

[2] Li, K. P., W. P. Carden, and R. H. Wagoner. Simulation of springback., International Journal of Mechanical Sciences 44.1(2002):103-122.

DOI: 10.1016/s0020-7403(01)00083-2

[3] Song Feifei, Yang He, Yang Yingli, et al. Research Status in Springback and its Control of Titanium Alloy tube Coled-bending, 31.6(2014):7-11.

[4] Gu, R. J., et al. Research on the springback of thin-walled tube NC bending based on the numerical simulation of the whole process., Computational Materials Science 42.4(2008):537-549.

DOI: 10.1016/j.commatsci.2007.09.001

[5] Song Feifei, et al. Springback prediction of thick-walled high-strength titanium tube bending., Chinese Journal of Aeronautics) 26.5(2013):1336-1345.

DOI: 10.1016/j.cja.2013.07.039

[6] Yang, et al. Some advanced plastic processing technologies and their numerical simulation., Journal of Materials Processing Tech 151.1(2004):63-69.

[7] Xing, Zhong Wen, et al. Numerical Research on High-Strength Rectangular Section Steel Tube in Rotary-Draw Bending., Key Engineering Materials 620(2014):417-423.

DOI: 10.4028/www.scientific.net/kem.620.417

[8] Zhan, Mei, et al. Springback analysis of numerical control bending of thin-walled tube using numerical-analytic method., Journal of Materials Processing Tech 177.1-3(2006):197-201.

DOI: 10.1016/j.jmatprotec.2006.03.183

[9] Jiang, Z. Q., et al. Establishment of a 3D FE model for the bending of a titanium alloy tube., International Journal of Mechanical Sciences 52.9(2010):1115-1124.

DOI: 10.1016/j.ijmecsci.2009.09.029

[10] Zhao Gangyao. Numerical simulation of buckling and wrinkling of thin - walled rectangular tube,.[D].Northwestern Polytechnical University. (2007).

[11] E, Da-Xin, et al. Spring-back deformation in tube bending., International Journal of Minerals Metallurgy and Materials 16.2(2009):177-183.

[12] Jiang, Z. Q., et al. Coupling effects of material properties and the bending angle on the springback angle of a titanium alloy tube during numerically controlled bending., Materials & Design 31.4(2010):2001-2010.

DOI: 10.1016/j.matdes.2009.10.029

[13] Zhu, Ying Xia, Y. L. Liu, and H. Yang. Sensitivity of springback and section deformation to process parameters in rotary draw bending of thin-walled rectangular H96 brass tube., Transactions of Nonferrous Metals Society of China 22.9(2012):2233-2240.

DOI: 10.1016/s1003-6326(11)61454-4
