Progress in Single Crystal Growth of Wide Bandgap Semiconductor SiC

Abstract:

The research and commercialization of SiC based power device have been burgeoning over the last decade worldwide, which is bringing about an increasing demand on lost-cost and low-defect SiC wafers. To meet this challenge, we have been continuously making efforts on improving the crystal growth and wafer processing techniques. Now, the mass-production of high quality 4-inch, 6-inch n-type and semi-insulating SiC wafers has been realized. Statistically, the micropipe density is lower than 0.5 cm^-2. The resistivity of the wafers is lower than 0.02 Ω·cm and up to 10⁸ Ω·cm for n-type and semi-insulating SiC single crystals, respectively. A state of the art processing technique has been developed to control wafer deformation and thickness within the desired values for subsequent epitaxy. The total defect number of the epitaxial layers grown on the "epi-ready" 4-inch SiC wafer is 63, and the usable area is 97.6%, indicating the high quality of our SiC substrates.

• Periodical: Materials Science Forum (Volume 954)
• Pages: 35-45
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.954.35
• Online since: May 2019
• Authors: Chun Jun Liu, T.H. Peng, B. Wang, Y. Guo, Y.F. Lou, N. Zhao, W.J. Wang, Xiao Long Chen*
• Keywords: Defect, Silicon Carbide, Single Crystal Growth, Wafer Processing

References

[1] G. Augustine, H.M. Hobgood, V. Balakrishna, G. Dunne, R.H. Hopkins, Physical vapor transport growth and properties of SiC monocrystals of 4H polytype, Phys. Stat. Sol. (b). 202(1997) 137-148.

DOI: 10.1002/1521-3951(199707)202:1<137::aid-pssb137>3.0.co;2-y

[2] H. Li, X.L. Chen, D.Q. Ni, X. Wu, Factors Affecting the Graphitization Behavior of the Powder Source during Seeded Sublimation Growth of SiC Bulk Crystal, J. Cryst. Growth, 258(2003) 100-105.

DOI: 10.1016/s0022-0248(03)01492-1

[3] H. Li, X.L. Chen, D.Q. Ni, X. Wu, An Analysis of Seed Graphitization for Sublimation Growth of SiC Bulk Crystal, Diamond Relat. Mater, 13 (2004) 151-156.

DOI: 10.1016/j.diamond.2003.10.030

[4] H. Li, D.Q. Ni, X. Wu, L.N. Zhu, X.L. Chen, A Heat Transfer Analysis for SiC Single Crystal Growth by PVT Method, Journal of synthesis crystal, 33(2004)510-515.

[5] L.N. Zhu, H. Li, D.Q. Ni, B.Q. Wu, X. Wu, X.L. Chen, New Type of Defects in SiC Grown by the PVT Method. Journal of physics: condensed matter, 17 (2005) L85–L91.

DOI: 10.1088/0953-8984/17/10/l01

[6] L. N. Zhu, X. L. Chen, H. Yang, T. H. Peng, D. Q. Ni, B. Q. Wu, Effects of Post-thermal Treatment on Quality of SiC Grown by PVT Method. Chin. Phys. Lett. 23(2006) 2273.

[7] T. H. Peng, H. Yang, J. K. Jian, W. J. Wang, W. Y. Wang, X. L. Chen, Factors Affecting the Formation of Misoriented Domains in 6H-SiC Single Crystals Grown by PVT Method. Cryst. Res. Technol. 44(2009)357-362.

DOI: 10.1002/crat.200800581

[8] T. H. Peng, Y. F. Lou, S. F. Jin, W. Y. Wang, W. J. Wang, G. Wang, X. L. Chen, Debye Temperature of 4H-SiC Determined by X-ray Powder Diffraction, Powder Diffraction, 24(2009)311-314.

DOI: 10.1154/1.3257905

[9] G. Wang, X. L. Chen, Single-crystal Growth: From New Borates to Industrial Semiconductors. Phys. Status Solidi A., 207(2010) 2757-2768.

DOI: 10.1002/pssa.201026453

[10] C.J. Liu, T.H. Peng, S.C. Wang, B. Wang, W. Sμn, G. Wang, W.J. Wang, X.L. Chen, Formation mechanism of Type 2 micropipe defects in 4H–SiC crystals. CrystEngComm, 15 (2013) 1307-1313.

DOI: 10.1039/c2ce26329g

[11] C.J. Liu, X.L. Chen，T. H. Peng, B. Wang, W.J. Wang, G. Wang, Step flow and polytype transformation in growth of 4H-SiC crystals. J. Cryst. Growth, 394 (2014)126-131.

DOI: 10.1016/j.jcrysgro.2014.02.027

[12] W. Sun, Y.T. Song, C.J. Liu, T.H. Peng, W.J. Wang, X.L. Chen, Basal plane dislocation –threading edge dislocation complex dislocations in 6H-SiC single crystals, Materials Express, 5(2015)63-68.

DOI: 10.1166/mex.2015.1212

[13] D. Gan, Y.T. Song, W. Sun, L.W. Guo and X. L. Chen, Origin of a fourfold symmetric (0 0 0 6) Bragg diffraction intensity in φ-scan mode on a 6H-SiC crystal, J. Phys. D: Appl. Phys. 48 (2015) 435105.

DOI: 10.1088/0022-3727/48/43/435105

[14] N. Zhao, C.J. Liu, B. Wang, T.H. Peng, Investigation of Stacking Faults in 4H-SiC Single Crystal, Journal of Inorganic Materials, 223(2018) 540.

[15] Information on http://www.tankeblue.com.
