A Study on Fastening the Switching Speed for Wide Bandgap Semiconductor Based Super Cascode

Abstract:

The Super Cascode is a series connected structure with a normally-off low voltage Si-MOSFET and multiple normally-on wide bandgap semiconductors. It has low switching losses compared with silicon based bipolar devices, and low on-resistance and low cost compared with other single high voltage normally-off wide bandgap semiconductor devices. In practice, however, there are inevitable parasitic inductances, which result in the increase of switching losses. The method is proposed to eliminate the common-source inductances (CSIs), such as using stack-die configuration with each device and adding an additional inductance in the gate loop of Si-MOSFET. It is numerically shown that the rise and fall times of the proposed method were 33.5% and 7.2% faster than the conventional one, respectively.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2018

View Preview

Info:

Periodical:

Materials Science Forum (Volume 963)

Pages:

823-826

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.963.823

Citation:

Cite this paper

Online since:

July 2019

Authors:

Xiang Guo Wang*, Masayuki Yamamoto

Keywords:

Kelvin Connection, Multi-Level Structure, Super Cascode

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] B. J. Baliga, Fundamentals of Power Semiconductor Devices, Springer, (2008).

Google Scholar

[2] J. Biela, D. Aggeler, D. Bortis, J.W. Kolar, Balancing circuit for a 5kV/50ns pulsed power switch based on SiC-JFET Super Cascode, IEEE Trans. on Plas. Sci. 40 (2012) 2554-2560.

DOI: 10.1109/ppc.2009.5386381

Google Scholar

[3] X. Li et al., Series-connection of SiC normally-on JFETs, Proc. of 27th ISPSD (2015) 221-224.

Google Scholar

[4] X. Li, H. Zhang, P. Alexandrov and A. Bhalla, Medium voltage power switch based on SiC JFET, IEEE 2016 APEC (2016) 2973-2980.

DOI: 10.1109/apec.2016.7468286

Google Scholar

[5] W. Zhang et al., A New Package of High-Voltage Cascode Gallium Nitride Device for Megahertz Operation, IEEE Trans. Power Ele. 31 (2016) 1344-1353.

DOI: 10.1109/tpel.2015.2418572

Google Scholar

[6] T. Ishikawa, Y. Tanaka, T. Yatsuo, K. Yano, SiC power devices for HEV/EV and a novel SiC vertical JFET, IEEE 2014 IEDM (2015) 24-27.

DOI: 10.1109/iedm.2014.7046964

Google Scholar
