Influence of Joint Configuration on Mechanical Properties of Laser Weld-Brazed Aluminum to Steel Joint

Abstract:

In the present work, laser weld-brazing experiments were performed to produce aluminum to galvanized steel joints in lap and flange configuration. Tests were carried out using Al-12 % Si eutectic filler wire for joining of AA6082 -T6 with galvanized steel with varying laser power and keeping other parameters (wire feed and laser scan speed) constant. Microstructural characteristics of the laser brazed joints, studied by SEM, revealed cast structure in the brazed zone. Intermetallic formed at the steel interface was non-uniform. From the hardness results, it was noted that the brazed region exhibits lower hardness compared to the base material. The wetting length was improved with increasing filler wire rate, which in turn improved the strength of the brazed joint in both the configuration (lap and flange). At 4 kW laser power, flange configuration sample has failed in AA6082 whereas, in case lap joint, failed in the heat affected zone of AA6082.

• Periodical: Materials Science Forum (Volume 978)
• Pages: 174-180
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.978.174
• Online since: February 2020
• Authors: D. Narsimha Chary, S.M. Shariff, Snehanshu Pal, G. Padmanabham, Anindya Basu*
• Keywords: AA6082, Flange-Joint, Lap-Joint, Laser-Brazing

References

[1] U. Dilthey, L. Stein, Multimaterial car body design: challenge for welding and joining, Sci. Technol Sci. Technol. Weld. Join. 11 (2006) 135-142.

DOI: 10.1179/174329306x85967

[2] H.T. Zhang, J.C. Feng, P. He, H. Hackl, Interfacial microstructure and mechanical properties of aluminium–zinc-coated steel joints made by a modified metal inert gas welding–brazing process, Mater. Charact. 58 (2007) 588-592.

DOI: 10.1016/j.matchar.2006.07.008

[3] D. J Small, P.J. Courtney, Fundamentals of Industrial Adhesives, Advanced Materials & Processes 163, (2005) 44–47.

[4] J. K Larsson, Reliable Joining Methods for Car Body Assembly with Challenges for Future Mixed Material Scenarios. Nordic Welding Conference, Oslo, Norway, 32, (2012).

[5] T. watanabe, H. Sakuyama, A. Yanagisawa, Ultrasonic welding between mild steel sheet and Al–Mg alloy sheet, J. Mater. Process. Technol, 209 (2009) 5475–5480.

DOI: 10.1016/j.jmatprotec.2009.05.006

[6] W.B. Lee, M. Schmuecker, U.A. Mercardo, G. Biallas, S. B. Jung, Interfacial reaction in steel–aluminum joints made by friction stir welding, Scr. Mater. 55 (2006) 355-358.

DOI: 10.1016/j.scriptamat.2006.04.028

[7] D. Narsimhachary S. Pal. S.M. Shariff, G. Padmanabham, A. Basu, AA6082 to DX56-Steel Laser Brazing: Process Parameter–Intermetallic Formation Correlation, J. Mater. Eng. Perform. 26 (2017) 4274-4281.

DOI: 10.1007/s11665-017-2902-5

[8] S.W. Mei, M. Gao, J. Yan, C. Zhang, G. Li, X.Y. Zeng, Interface properties and thermodynamic analysis of laser–arc hybrid welded Al/steel joint. Sci. Technol, Weld. Joining. 18 (2013) 293-300.

DOI: 10.1179/1362171813y.0000000106

[9] H. Laukant, C. Wallmann, M. Müller, M. Korte, B. Stirn, H.G. Haldenwanger, U. Glatzel, Fluxless laser beam joining of aluminium with zinc coated steel, Sci. Technol. Weld. Join. 10 (2005) 219–226.

DOI: 10.1179/174329305x37051

[10] L. A, Jácome, S.Weber, A. Leitner, E. Arenholz, J. Bruckner, H. Hackl, A. R. Pyzalla, Influence of filler composition on the microstructure and mechanical properties of steel–aluminum joints produced by metal arc joining, Adv. Eng. Mater. 11 (2009) 350–358.

DOI: 10.1002/adem.200800319

[11] K.P. Yagati, R.N. Bathe, K.V. Rajulapati, K.B.S. Rao, G. Padmanabham, Fluxless arc weld-brazing of aluminium alloy to steel, J. Mater. Process. Technol. 214 (2014) 2949-2959.

DOI: 10.1016/j.jmatprotec.2014.06.017

[12] D. Narsimhachary, K. Dutta, S. M. Shariff, G. Padmanabham, A. Basu: Mechanical and microstructural characterization of laser weld-brazed AA6082-galvanized steel joint J. Mater. Process. Technol. 263 (2019) 21-32.

DOI: 10.1016/j.jmatprotec.2018.08.002

[13] M. Gatzen, T. Radel, C. Thomy, F. Vollertsen, Wetting behaviour of eutectic Al–Si droplets on zinc coated steel substrates, J. Mater. Process. Technol. 214 (2014) 123–131.

DOI: 10.1016/j.jmatprotec.2013.08.005

[14] S. Frank, Flux-free laser joining of aluminium and galvanized steel, J. Mater. Process. Technol. 222 (2015) 365–72.
