Iron Nanostructures Fabricated by Electron Beam Induced Deposition and its Magnetic Properties

Abstract:

Electron beam induced deposition (EBID) was carried out with gas introduction systems attached to field emission scanning electron microscope (FE-SEM). Using iron carbonyl and ferrocene, three dimensional (3-D) antenna structures were fabricated in the range of 30-50 nm in diameter and 500-1000 nm in size. Post-deposition annealing of iron nanostructures resulted in the formation of crystalline alpha-iron and iron carbide phases. The iron concentration was controlled by the partial pressure of iron carbonyl and ferrocene. Electron holography observation with field emission transmission electron microscopy (FE-TEM) revealed that the remanent magnetic flux density Br of the nanostructures also depends on the iron concentration.

You might also be interested in these eBooks

Advances in Nanomaterials and Processing

View Preview

Info:

Periodical:

Solid State Phenomena (Volumes 124-126)

Pages:

139-142

DOI:

https://doi.org/10.4028/www.scientific.net/SSP.124-126.139

Citation:

Cite this paper

Online since:

June 2007

Authors:

Kazuo Furuya, Masaki Takeguchi, Kazutaka Mitsuishi

Keywords:

3-D Antenna Structure, EBID, Electron Holography, Ferrocene, Iron Carbonyl

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] M. Takeguchi, M. Shimojo and K. Furuya: Nanotechnology Vol. 16 (2005), p.1321.

Google Scholar

[2] R. R. Kunz and T. M. Mayer: Appl. Phys. Lett. Vol. 50 (1987), p.962.

Google Scholar

[3] I. Utke, P. Hoffmann, R. Berger and L. Scandella: Appl. Phys. Lett. Vol. 80 (2002), p.4792.

Google Scholar

[4] M. Han, K. Mitsuishi, M. Shimojo and K. Furuya: Philos. Mag. Vol. 84 (2004), p.1281.

Google Scholar

[5] M. Shimojo, M. Takeguchi, M. Tanaka, K. Mitsuishi and K. Furuya: Appl. Phys. A Vol. 79 (2004), p.1869.

Google Scholar

[6] M. Takeguchi, M. Shimojo and K. Furuya: Jpn. J. Appl. Phys. Vol. 44 (2005), p.5631.

Google Scholar

[7] Z. Q. Liu, K. Mitsuishi and K. Furuya: J. Appl. Phys. Vol. 96 (2004), p.619.

Google Scholar

[8] A. R. Sethuraman, J. M. Stencel, A. M. Rubel, B. Cavin and C. R. Hubbard: J. Vac. Sci. Technol. A Vol. 12 (1994), p.443.

Google Scholar

[9] P. A. Midgley: Micron Vol. 32 (2001), p.167.

Google Scholar

[10] M. Takeguchi, M. Shimojo, R. Che and K. Furuya: J. Mater. Sci. Online First (2006).

Google Scholar

[11] M. Takeguchi, M. Shimojo, K. Mitsuishi, M. Tanaka, R. Che and K. Furuya: J. Mater. Sci. In press (2006).

Google Scholar
