Preparation and Characterization of PrAlO₃-Doped 0.95MgTiO₃-0.05CaTiO₃ Microwave Dielectric Ceramics

Abstract:

Microwave dielectric ceramics with a nominal composition of 0.95MgTiO₃-0.05CaTiO₃- xPrAlO₃ (x=0-0.015) were prepared by conventional solid-state sintering. The phase composition, microstructure and dielectric properties were characterized by X-ray diffractometer, scanning electron microscope and vector network analyzer, respectively. A two-phase system with major MgTiO₃ phase and minor CaTiO₃ phase was detected. With increasing content of PrAlO₃, the grain size of the obtained ceramics decreased; the dielectric constant and quality factor increased first and then decreased. The temperature coefficient of resonant frequency decreased after PrAlO₃ was doped, but with more PrAlO₃ doped it will increase. The obtained 0.95MgTiO₃-0.05CaTiO₃ ceramic doped by PrAlO₃ with x=0.0075 presented the best performance with ε_r=19.04, Q·f=42400 GHz and τ_f=-19.40 ppm/°C.

• Periodical: Solid State Phenomena (Volume 281)
• Pages: 579-584
• DOI: https://doi.org/10.4028/www.scientific.net/SSP.281.579
• Online since: August 2018
• Authors: Lu Zhi Xie, Jun Qing Ren, Zhi Jian Peng*, Xiu Li Fu
• Keywords: 0.95MgTiO₃-0.05CaTiO₃, Doping, Microwave Dielectric Property, PrAlO₃

References

[1] M.T. Sebastian, R. Ubic, H. Jantunen, Low-loss dielectric ceramic materials and their properties, Int. Mater. Rev. 60 (2015) 392-412.

DOI: 10.1179/1743280415y.0000000007

[2] C.H. Hsu, C.J. Huang, Preparation, structural and microwave dielectric properties of CaLa4(ZrxTi1-x)4O15 ceramics, J.Alloy. Compd. 587 (2014) 45-49.

DOI: 10.1016/j.jallcom.2013.10.168

[3] H. Ohsato, T. Tsunooka, A. Kan, et al., Microwave-millimeter wave dielectric materials, Key Eng. Mater. 269 (2004) 195-198.

DOI: 10.4028/www.scientific.net/kem.269.195

[4] L.X. Li, S. Li, T. Tian, Microwave dielectric properties of (1-x)MgTiO3-x(Ca0.6Na0.2Sm0.2)TiO3 ceramic system, J. Mater. Sci-Mater. Electron. 27 (2016) 1286-1292.

DOI: 10.1007/s10854-015-3887-1

[5] R.C. Pullar, J.D. Breeze, N.M. Alford, Microwave dielectric properties of columbite-structure niobate ceramics, M2+Nb2O6, Key Eng. Mater. 224-2 (2002) 1-4.

DOI: 10.4028/www.scientific.net/kem.224-226.1

[6] K. Wakino, Recent development of dielectric resonator materials and filters in Japan,Ferroelectrics 91 (1989) 69-86.

DOI: 10.1080/00150198908015730

[7] Y. Yang, R.L. Fu, S. Agathopoulos, Influence of the processing way for La3+-doping on crystal structure, microstructure, and microwave dielectric properties of Ca0.7Ti0.7La0.3Al0.3O3 ceramics,Ceram. Int. 42 (2016)18108-18115.

DOI: 10.1016/j.ceramint.2016.08.123

[8] B. Jancar, D. Suvorov, M. Valant, Characterization of CaTiO3-NdAlO3 dielectric ceramics,J. Eur. Ceram. Soc.23 (2003) 1391-1400.

DOI: 10.1016/s0955-2219(02)00359-x

[9] L.X. Li, Z.D. Gao, Y.R. Liu, et al., Influence of LaAlO3 additive to MgTiO3-CaTiO3 ceramics on sintering behavior and microwave dielectric properties,Mater. Lett. 140 (2015) 5-8.

DOI: 10.1016/j.matlet.2014.10.154

[10] J. Liu, C.W. Zhong, Y. Tao, et al., Microwave dielectric characteristics of NdAlO3-doped 0.95MgTiO3-0.05CaTiO3 ceramics,J. Mater. Sci-Mate.Electron. 28 (2017) 909-914.

DOI: 10.1007/s10854-016-5606-y

[11] Y. Kobayashi, M. Katoh, Microwave measurement of dielectric properties of low-loss materials by the dielectric rod resonator method, IEEE T. Microw. Theory 33 (1985) 586-592.

DOI: 10.1109/tmtt.1985.1133033

[12] I.M. Reaney, D. Iddles, Microwave dielectric ceramics for resonators and filters in mobile phone networks, J. Am. Ceram. Soc. 89(2006) 2063-(2072).

DOI: 10.1111/j.1551-2916.2006.01025.x

[13] R.D. Shannon, Dielectric polarizabilities of ions in oxides and fluorides, J. Appl.Phys.73 (1993) 348-366.

[14] J. Petzelt, N.Setter, Far infrared spectroscopy and origin of microwave losses in low-loss ceramics, Ferroelectrics150 (1993) 89-102.

DOI: 10.1080/00150199308008697

[15] M.K. Park, H.N. Kim, K.S. Lee, et al., Effect of microstructure on dielectric properties of Si3N4 at microwave frequency, Key Eng. Mater. 287 (2005) 247-252.

[16] F. Liu, X.Y. Liu, C.L. Yuan, Microstructures and microwave dielectric properties of (1-x)Sr0.4Na0.3La0.3TiO3-xLnAlO3 (Ln=Sm, Nd) ceramic systems, J. Eur. Ceram. Soc. 35 (2015) 2091-(2098).

DOI: 10.1016/j.jeurceramsoc.2015.01.007

[17] I.M. Reaney, E.L. Colla,N.Setter,Dielectric and structural characteristics of Ba-based and Sr-based complex perovskites as a function of tolerance factor,Jpn. J. Appl. Phys. 33 (1994) 3984-3990.

DOI: 10.1143/jjap.33.3984

[18] F. Liu, X.Y. Liu, C.L. Yuan, Crystal structure and dielectric properties of (1-x)SrTiO3- xCa0.4Sm0.4TiO3 ceramic system at microwave frequencies, Mater. Chem. Phys. 148 (2014) 1083-1088.
