Investigation of Simple Process Technology for the Fabrication of Valveless Micropumps

Abstract:

This paper presents a simple process technique for the fabrication of valveless micro-pumps. The process design utilizes standard MEMS process using double-sided anisotropic silicon wet etching process with an additional adhesive bonding technique. The diffuser and nozzle element of the pump with depth of 50 µm, as well as a 150 µm thick silicon membrane are designed and fabricated using only 3 patterning process steps. A piezoelectric plate working at the frequency range from 0.1 kHz to 2 kHz is bonded on to the back side of the silicon membrane to create the membrane actuation. The patterning process of thick photoresist used as the adhesive layer for the substrate bonding is also discussed in detail. The fluid flow is observed and the process reproducibility is proven which show a good prospect for the future development of miniaturized valveless pump for biomedical application.

• Periodical: Advanced Materials Research (Volume 254)
• Pages: 211-214
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.254.211
• Online since: May 2011
• Authors: Jumril Yunas, Juliana Johari, Ali Reza Bahadorimehr, Ille C. Gebeshuber, Majlis Burhanuddin Yeop
• Keywords: Adhesive Bonding, Micro-Electromechanical System (MEMS), Valveless Micropump, Wet Etching

References

[1] Y. C. Lim, A.Z. Kouzani and W. Duan, Lab-on-a-chip: a component view, Microsystem Technologies 16 (2010) 1995–(2015)

DOI: 10.1007/s00542-010-1141-6

[2] H.K. Ma, B.R. Hou, C. Yao Lin and J.J. Gao, The improved performance of one-side actuating diaphragm micropump for a liquid cooling system, International Communications in Heat and Mass Transfer 35 (2008) 957–966

DOI: 10.1016/j.icheatmasstransfer.2008.04.002

[3] F. Amirouche, Y. Zhou and T. Johnson, Current micropump technologies and their biomedical applications, Microsystem Technology, 15 (2009) 647-666

DOI: 10.1007/s00542-009-0804-7

[4] K. Junwu, Y. Zhigang, P. Taijiang, C. Guangming and W. Boda, Design and test of a high-performance piezoelectric micropump for drug delivery, Sensors and Actuators A 121 (2005) 156–161

DOI: 10.1016/j.sna.2004.12.002

[5] J. Johari, J. Yunas and B.Y. Majlis, Piezoelectric Micropump for Drug Delivery System Fabricated Using Two Optical Masks, Advanced Materials Research, 74 (2009) 279-282

DOI: 10.4028/www.scientific.net/amr.74.279

[6] N. Soin and B.Y. majlis, Development of Perfect Silicon Corrugated Diaphragm using Anisotropic Etching, Microelectronic Engineering, 83, Issue: 4-9 (2006) 1438-1441

DOI: 10.1016/j.mee.2006.01.084
