Experimental and Predictive Study of the Flexural Behavior of Self-Compacting Rubberized Steel-Reinforced Concrete

Abstract:

This paper presents the results of a study that aimed to analyze the flexural behavior of self-compacting rubberized steel-reinforced concrete. A four-point bending test was performed on three reinforced beams made with conventional concrete and three similar beams made using the same concrete mixture with a 10% volumetric substitution of natural aggregates with rubber particles. The results showed a statistically significant decrease (about 24%) in the cracking load for the rubberized concrete beams, which is attributed to the reduced indirect tensile strength and modulus of the rubberized concrete. However, no statistically significant difference was observed between the control and rubberized concrete beams in terms of ultimate load and maximum deflection Additionally, the estimated adhesion strength, based on the average measured crack spacing, was also statistically similar between the tested beams. Existing equations derived from reinforced concrete beam theory were deemed suitable for rubberized concrete, since the estimation trends for these equations were similar for both types of concrete. Therefore, the main conclusion of this study is that the presence of rubber particles, at a 10% volumetric substitution, did not affect the flexural behavior particularly the quality of adhesion between the reinforcing bars and the surrounding concrete of steel-reinforced beams.

• Periodical: International Journal of Engineering Research in Africa (Volume 77)
• Pages: 135-153
• DOI: https://doi.org/10.4028/p-srJJo3
• Online since: December 2025
• Authors: Jihen Mallek*, Amara Loulizi, Atef Daoud, Othman Omikrine-Metalssi
• Keywords: Adhesion Strength, Four-Point Bending, Rubberized Self-Compacting Concrete, Sustainability

References

[1] A.T. Akono, J. Chen, S. Kaewunruen, Friction and fracture characteristics of engineered crumb-rubber concrete at microscopic length scale. Construction and Building Materials, 175, (2018) 735–745.

DOI: 10.1016/j.conbuildmat.2018.04.141

[2] R. Wang, X. He, Y. Li, Evaluation of microcracks in the interfacial transition zone of recycled rubber concrete. Structural Concrete, 20, (2019) 1684–1694.

DOI: 10.1002/suco.201900044

[3] A. Gargouri, A. Daoud, A. Loulizi, A. Kallel, Laboratory Investigation of Self-Consolidating Waste Tire Rubberized Concrete. ACI Materials Journal, 113, (2016) 661–668.

DOI: 10.14359/51688991

[4] J. Mallek, A. Daoud, O. Omikrine-Metalssi, A. Loulizi, Performance of self-compacting rubberized concrete against carbonation and chloride penetration. Structural Concrete, (2021) 1–16.

DOI: 10.1002/suco.202000687

[5] N. Ganesan, J. Bharati Raj, A.P. Shashikala, Flexural fatigue behaviour of self-compacting rubberized concrete. Construction and Building Materials, 44, (2013) 7–14.

DOI: 10.1016/j.conbuildmat.2013.02.077

[6] A.S. Ali, T.M. Hasan, Flexural Behavior of Fiber Reinforced Self-Compacting Rubberized Concrete Beams. Journal of Engineering, 26(2), (2020).

DOI: 10.31026/j.eng.2020.02.09

[7] J. Mallek, O. Omikrine-Metalssi, A. Loulizi, A. Daoud, Durability of self-compacting rubberized concrete exposed to external sulphate attack. Case Studies in Construction Materials, 20, (2024) e02730.

DOI: 10.1016/j.cscm.2023.e02730

[8] K. Mushunje, M. Otieno, Y. Ballim, A review of waste tyre rubber as an alternative concrete constituent material. MATEC Web of Conferences, 199, (2018) 11003.

DOI: 10.1051/matecconf/201819911003

[9] S.M. Agampodi, S. Al-Deen, M. Ashraf, Effect of rubber particles on the flexural behaviour of reinforced crumbed rubber concrete beams. Construction and Building Materials, 154, (2017) 644–657.

DOI: 10.1016/j.conbuildmat.2017.07.220

[10] M.K. Ismail, A.A. Hassan, An experimental study on flexural behaviour of large-scale concrete beams incorporating crumb rubber and steel fibres. Engineering Structures, 145, (2017) 97–108.

DOI: 10.1016/j.engstruct.2017.05.018

[11] H.A. Alasmari, B.H. Abu Bakar, A.T. Noaman, A Comparative Study on the Flexural Behaviour of Rubberized and Hybrid Rubberized Reinforced Concrete Beams. Civil Engineering Journal, 5(5), (2019).

DOI: 10.28991/cej-2019-03091311

[12] N. Abu Bakar, M.R.N. Noaman, N.A.M. Nasir, N.A. Safee, Experimental evaluation of flexural behaviour of rubberized concrete beam. Asian Journal of Civil Engineering, (2019).

DOI: 10.1007/s42107-019-00159-5

[13] D. Sinkhonde, R. Ocharo Onchiri, W. Odhiambo Oyawa, J. Nyiro Mwero, Ductility performance of reinforced rubberized concrete beams incorporating burnt clay powder. Heliyon, 7, (2021) e08310.

DOI: 10.1016/j.heliyon.2021.e08310

[14] I.A. Sharaky, M.H. Seleem, A.S. Elamary, Minimizing the crumb rubber effects on the flexural behaviour of layered RC beams cast using rubberized concrete with or without recycled tire steel fibers. Construction and Building Materials, 400, (2023) 132503.

DOI: 10.1016/j.conbuildmat.2023.132503

[15] A. Abdo, M.T. Elshazli, Y. Alashker, S. Ahmed, Improving flexural response of rubberized RC beams with multi-dimensional sustainable approaches. Construction and Building Materials, 449, (2024) 138400.

DOI: 10.1016/j.conbuildmat.2024.138400

[16] CEB-FIP Model Code, fib Model Code for Concrete Structures. Comité Euro-International du Béton, 2010.

[17] AFNOR, NF EN 197-1, Cement - Part 1: composition, specifications and conformity criteria for common cements. April 2012.

[18] NF EN ISO 9001, Quality management systems – Requirements. October (2015)

[19] F. De Larrard, Concrete mixture proportioning: a scientific approach. London, UK: E&FN Spon; 1999, 448.

[20] AFNOR, EN 12350-6, Testing fresh concrete – Part 6: Density test. June 2019.

[21] AFNOR, EN 12350-8, Testing fresh concrete – Part 8: Self-compacting concrete – Slump-flow test. June 2019.

DOI: 10.3403/30210219

[22] AFNOR, EN 12350-10, Testing fresh concrete – Part 10: Self-compacting concrete – L box test. November 2010.

[23] AFNOR, EN 12350-11, Testing fresh concrete – Part 11: Self-compacting concrete – Sieve stability test. November 2010.

DOI: 10.3403/30210228u

[24] AFNOR, NF X15 206, Laboratory fume cupboards – Threshold for confinement and speed tests. August 2023.

[25] AFNOR, EN 12390-3, Testing hardened concrete – Part 3: compressive strength of test specimens. June 2019.

[26] AFNOR, EN 12390-6, Testing hardened concrete – Part 6: tensile splitting strength of test specimens. November 2023.

DOI: 10.3403/30454320

[27] AFNOR, NF EN ISO 179, Plastics - Determination of Charpy impact properties - Part 1: non-instrumented impact test. June 2023.

DOI: 10.3403/30192289

[28] Bulletin d'information N°158-E, Comité Euro International Du Béton (CEB) – Manual on cracking and déformation. 1985.
