Damping Properties of Epoxy-Embedded Piezoelectric Composites

Abstract:

The 0-3 and 1-3 composites have been widely used to produce various kinds of piezoelectric devices. This article focuses on the damping properties of the epoxy/piezoelectric composites. Due to the piezoelectric effect, the composites are expected to improve the damping properties and can be used in the field of vibration reduction and noise control. Two piezoelectric materials were embedded into the epoxy resin to make specimens, T-ZnOw/epoxy resin as 0-3 and PZT fibers/epoxy resin as 1-3 composite. With the method of dynamic mechanical analysis, the temperature dependence of the mechanical storage modulus and the loss factor (tanδ) were measured at different frequencies. The experimental results clearly show that the loss factor increases when testing frequency is higher. In this study, the piezoelectric damping and the viscoelastic effect are discussed and both of them contribute to the damping property of the composite system.

• Periodical: Key Engineering Materials (Volumes 512-515)
• Pages: 1342-1346
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.512-515.1342
• Online since: June 2012
• Authors: Xuan Qing Hong, Xu Sheng Wang, Xiang Ming Li, Rui Chen, Xi Yao, Zhao Jin Sun, Jian Qiang Guo
• Keywords: DMA, Piezo-Damping, PZT Fibers, T-ZnOw

References

[1] G.S. Agnes, Development of a modal model for simultaneous active and passive piezoelectric vibration suppression, J. Intell. Mater. Syst. Struct. 6 [4] (1995) 482-487

DOI: 10.1177/1045389x9500600405

[2] R.E. Newnham, D.P. Skinner and L.E. Cross, Connectivity and piezoelectric-pyroelectric composites, Mater. Res. Bull. 13 [5] (1978) 525-536

DOI: 10.1016/0025-5408(78)90161-7

[3] N.W. Hagood and A. von Flotow, Damping of structural vibrations with piezoelectric materials and passive electrical networks, J. Sound. Vib. 146 [2] (1991) 243-268

DOI: 10.1016/0022-460x(91)90762-9

[4] H. Ghoneim, Application of the electromechanical surface damping to the vibration control of a cantilever plate, J. Vib. Acoust. 118 [4] (1996) 551-557

DOI: 10.1115/1.2888334

[5] G. Caruso, A critical analysis of electric shunt circuits employed in piezoelectric passive vibration damping, Smart. Mater. Struct. 10 (2001) 1059-1068

DOI: 10.1088/0964-1726/10/5/322

[6] M. Hori, T. Aoki, Y. Ohira et al., New type of mechanical damping composites composed of piezoelectric ceramics, carbon black and epoxy resin, Compos. Part. A. 32 (2001) 287-290

DOI: 10.1016/s1359-835x(00)00141-x

[7] H.A. Sodano, G. Park and D.J. Inman, An investigation into the performance of macro-fiber composites for sensing and structural vibration applications, Mech. Syst. Signal. Pr. 18 (2004) 683-697

DOI: 10.1016/s0888-3270(03)00081-5

[8] R.M. Christensen: Theory of Viscoelasticity: An Introduction 2nd ed., Academic Press, New York, 1982.

[9] B.E. Read, G.D. Dean and J.C. Duncan, Determination of Dynamic Moduli and Loss Factors, in: B.W. Rossiter and R.C. Baetzold (Eds.), Determination of Elastic and Mechanical Properties, Volume 7 of Physical Methods of Chemistry, 2nd ed., John Wiley & Sons (1991)

[10] H.H. Law, P.L. Rossiter, L.L. Koss and G.P. Simon, Mechanisms in damping of mechanical vibration by piezoelectric ceramic-polymer composite materials, J. Mater. Sci. 30 (1995) 2648-2655

DOI: 10.1007/bf00362148
