Phase Transitions, Dielectric and Piezoelectric Properties of BiScO₃-PbTiO₃ Ceramic Solid Solutions

Abstract:

Dielectric and piezoelectric properties of ceramic solid solutions based on the compositions close to the MPB in the system (1-x)BiScO3 – xPbTiO3 (x- 0.63, 0.635, 0.64) have been studied. The 1st order phase transitions were observed at temperatures near 700 K. Increase in the lead titanate content stimulates slight increase in the TC value. Cr2O3 additives in amounts up to 0.2 w. % favor to the decrease of total conductivity and dielectric loss at high temperatures. Increase in the d33 and kt piezocoefficients was observed in modifed ceramic. Besides peaks in temperature dependences of dielectric permittivity and dielectric loss marked ferroelectric to paraelectric phase transitions, effects of dielectric relaxation, determined by oxygen vacancies were revealed.

• Periodical: Key Engineering Materials (Volumes 512-515)
• Pages: 1363-1366
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.512-515.1363
• Online since: June 2012
• Authors: Ekaterina D. Politova, Galina M. Kaleva, Alexander V. Mosunov, Andrei G. Segalla, Jiang Tao Zeng
• Keywords: BiScO₃-PbTiO₃, Chromium Oxide Additives, Ferroelectric, Piezoelectric Properties

References

[1] B. Jaffe, W.R. Cook and H. Jaffe, Piezoelectric ceramics, Academic Press, London and New York, 1971.

[2] Y. Higuchi, H. Ogawa, D. Kuroda, M. Kimura, H. Takagi, Y. Sakabe, Piezoelectric ceramics for high temperature applications, Key Engineering Materials 421-422 (2010) 375-380.

DOI: 10.4028/www.scientific.net/kem.421-422.375

[3] B. Noheda, J.A. Gonzalo, L.E. Cross, et al., Tetragonal-to-monoclinic phase transition in a ferroelectric perovskite: The structure of PbZr0.52Ti0.48O3, Phys. Rev. B 61 (2000) 8687-8695.

[4] D. Damjanovic, A morphotropic phase boundary system based on polarization rotation and polarization extension, Appl. Phys. Lett. 97 (2010) 062906 (1-3).

DOI: 10.1063/1.3479479

[5] V. Gupta, M. Sharma, and N. Thakur, Optimization Criteria for Optimal Placement of Piezoelectric Sensors and Actuators on a Smart Structure: A Technical Review, V. Gupta, M. Sharma, N. Thakur, Journ. Intell. Mater. Sys. Str.J. Intel. Mat. Sys. Str. 21, (2010) 1227-1243.

DOI: 10.1177/1045389x10381659

[6] Yu.Ya. Tomashpol'skii, E.V. Zubova, K.P. Burdina, Yu.N. Venevtsev, X-ray diffraction study of of new perovskites prepared at high pressures, Kristallographiya (in Russian), 13 (1968) 987-990.

[7] R.E. Eitel, C.A. Randall, T.R. Shrout, S.-E. Park, Preparation and characterization of high temperature perovskite ferroelelctrics in the solid solutions (1-x)BiScO3-xPbTiO3, Jpn. J. Appl. Phys. 41 (2002) 2099-2104.

DOI: 10.1143/jjap.41.2099

[8] J Iniguez, D. Vanderbilt, L. Bellaiche, First- principles study of (BiScO3)1-x-(PbTiO3)x piezoelectric alloys, Phys. Rev. B 67 (2003) 224107 (1-6).

[9] R.E. Eitel, S.J. Zhang, T.R. Shrout, I. Levin, C.A. Randall, Phase Diagram of the Perovskite system (1-x)BiScO3-xPbTiO3, J. Appl. Phys. 96 (2004) 2828-2831.

DOI: 10.1063/1.1777810

[10] S. Zhang, R.E. Eitel, C.A. Randall, T.R. Shrout, Manganese-modified BiScO3-PbTiO3 piezoelelctric ceramic for high-temperature shear mode sensor, Appl. Phys. Lett. 86 (2005) 262904 (1-3).

DOI: 10.1063/1.1968419

[11] T. Zou, X. Wang, W. Zhao, L. Li, Preparation and properties of fine-grain (1-x)BiScO3-xPbTiO3 ceramics by two-step sintering, J. Amer. Ceram. Soc. 91 (2008) 121-126.

DOI: 10.1111/j.1551-2916.2007.01903.x

[12] L. Zhang, Zh. Xu, Zh Li, S. Hia, Xi Yao, Preparation and characterization of high Tc (1-x)BiScO3- xPbTiO3 ceramics from high energy ball milling process, J. Electroceram. 21 (2008) 605-608.

DOI: 10.1007/s10832-007-9282-4

[13] A. Sehirlioglu, A. Sayir, F. Dynys, High temperature properties of BiScO3-PbTiO3 piezoelectric ceramics, J. Appl. Phys. 105 (2009) 114102 (1-7).

DOI: 10.1063/1.3158542

[14] M. Alguero, H. Amorin, T. Hungria, J. Galy, A. Castro, Macroscopic ferroelectricity and piezo- electricity in nanostructured BiScO3-PbTiO3 ceramics, Appl. Phys. Lett. 94 (2009) 012902 (1-8).

DOI: 10.1063/1.3056660

[15] B. Kim, P. Tong, D. Kwon, et al., Temperature-dependent neutron diffraction study of phase separation at morphotropic phase boundary in (1-x)BiScO3-xPbTiO3, J. Appl. Phys. 105 (2009) 114101 (1-6).

DOI: 10.1063/1.3130402

[16] B.V. Egorova, E.D. Politova, G.M. Kaleva, A.V. Mosunov, S.Yu. Stefanovich, A.G. Segalla, J. Zeng, Phase Transitions and the Dielectric and Piezoelectric Properties of Ceramic Solid Solutions Based on BiScO –PbTiO3, Bull. Russ. Acad. Sci. 75 (2011) 1166-1169.

DOI: 10.3103/s1062873811050418

[17] A.V. Mosunov, N.U. Venskovskii, G.M. Kaleva, Dielectric properties of oxygen ion-conductive (La,Sr)(Ga,Mg)O3 ceramics, Ferroelectrics 299 (2004) 149-152.

DOI: 10.1080/00150190490429565

[18] W. Li, C. Wang, J. Zhu, and Y. Wang, Correlation among oxygen vacancies and its effect on fatigue in neodymium-modified bismuth titanate ceramics, J. Phys.: Condens. Matter 16 (2004) 9201-9208.

DOI: 10.1088/0953-8984/16/50/011

[19] E.D. Politova, E.A. Fortalnova, G.M. Kaleva, et al., Ferroelectric phase transitions and electrocon- ducting properties of ceramic BIMEVOX solid solutions (Me = La, Zr), Ferroelectrics 391 (2009) 3-11.

DOI: 10.1080/00150190903001045

[20] M.I. Morozov, D. Damjanovic, Charge migration in Pb(Zr,Ti)O3 ceramics and its relation to ageing, hardening and softening, J. Appl. Phys. 107 (2010) 034106 (1-10).

DOI: 10.1063/1.3284954
