Origin of Large Bumps Abnormally Grown on 4H-SiC Epitaxial Film by Adding HCl Gas with High Cl/Si Ratio in CVD Process

Abstract:

4H-SiC homo-epitaxial film was grown by adding HCl gas with a high Cl/Si ratio in CVD process, and defect formation and origin of the defect were investigated by confocal differential interference contrast (CDIC) microscope, PL imaging and normal differential interference contrast (DIC) microscope. It was found that a large number of large bumps are formed on the film grown at a high Cl/Si ratio of 30, and a large number of PL defects on bare substrate before the film growth are also observed. Coordinates where the bumps on the film are observed were good agreement with those where the PL defects on the bare substrate are observed. An etch pit sample on reproduced substrate from which epitaxial film was removed was fabricated by etching process using molten KOH+Na₂O₂, and some types of etch pits which might be originated from threading edge dislocations (TEDs), threading screw dislocations (TSDs) and basal plane dislocations (BPDs) in the substrate were observed. The coordinates where the etch pits on the reproduced substrate are observed were also good agreement with those where the bumps on the epitaxial film are observed. Therefore, it was clarified that a large number of the bumps abnormally grown on the epitaxial film are originated from the dislocations in the substrate.
