Experimental Investigation of a 10 kV-70A Switch with Six SiC-MOSFETs in a Series-Connection Configuration

Abstract:

In this paper, a prototype of 6 series-connected SiC-MOSFETs for double pulses test purpose is presented. This prototype represents many challenges amongst which the measurements of voltage sharing and the EMI issues due to high dv/dt. High voltage tests are performed up to 8 kV at 65A and voltage balancing, losses and switching speeds are evaluated. Switching speed up to 520 V/ns are recorded.

By email View Pdf

You have full access to the following eBook

Silicon Carbide and Related Materials 2021

Read eBook

Info:

Periodical:

Materials Science Forum (Volume 1062)

Pages:

472-476

DOI:

https://doi.org/10.4028/p-cg93gc

Citation:

Cite this paper

Online since:

May 2022

Authors:

Cédric Mathieu de Vienne*, Pierre Lefranc, Besar Asllani, Pierre Olivier Jeannin, Bruno Lefebvre

Keywords:

Series-Connection, SiC-MOSFET

Export:

RIS, BibTeX

Permissions:

Creative Commons CC BY 4.0
