Study on Homoepitaxy Performance of Engineered 150 mm and 200 mm SiC Substrates in a Multi-Wafer Batch Reactor

Article Preview

Abstract:

Engineered SiC wafers with a thin 4H-SiC layer bonded on a polycrystalline carrier substrate for the application as substrate in epitaxy are investigated. Epitaxial layers grown on such substrates in 150 mm and 200 mm diameter are compared to those on state-of-the-art conventional substrates from different vendors. The performance of the engineered wafers is judged by doping and thickness uniformities as well as the number and statistics of killer defects in the epitaxial layer.
